SNMP MIBs and Traps, and RMON Alarm Defaults
B-13
9783-A2-GB20-00
July 2000
Table B-7. enterprise-Specific Traps and Variable-Bindings (2 of 3)
Trap Possible CauseVariable-Bindings
enterpriseMissedSLV-
Down(16)
H devFrExtDlciIfIndex
(devFrExt.mib)
H devFrExtDlciDlci
(devFrExt.mib)
H devFrExtDlciMissed-
SLVs
(
devFrExt.mib
)
SLV Timeout Error Event
Threshold has been exceeded.
String:
‘SLV down on $ifString due to
excessive SLV packet loss. Total
SLV packets lost is $numLost.’
enterpriseMissedSLV-
Up(116)
SLVs
(devFrExt
.
mib)
H devLastTrapString
(devHealthAndStatus.-
mib.)
SLV Timeout Error Event has
been cleared.
String:
‘SLV up on $ifString because
SLV communication was
reestablished. Total SLV packets
lost is $numLost.’
enterpriseRMON-
ResetToDefault(13)
H devLastTrapString
(devHealthAndStatus.-
mib)
All RMON-related option
changes have been reset to their
default values.
Default Factory Configuration
settings have been reloaded,
returning RMON-related options
to their original settings.
String:
‘RMON database reset to
defaults.’
enterpriseSelfTest-
Fail(2)
H devLastTrapString
(devHealthAndStatus.-
mib)
Unit has completed
(re)initialization and a hardware
failure was detected.
String:
‘Self test failed: $
s
.’ ($
s
is the
contents of devSelfTestResult.)
