SNMP MIBs and Traps, and RMON Alarm Defaults
B-4
9783-A2-GB20-00July 2000
Interfaces Group (mib-2)
Clarification for objects in the Interfaces Group, as defined in RFC 1573 and
RFC 1213, which is an SNMPv1 MIB, is provided in this section.
Paradyne Indexes to the Interface Table (ifTable)
The following table provides the ifName for each interface type, the ifDescr, and
the ifIndex that Paradyne has assigned to each.
Table B-1. Paradyne Interface Objects Information
ifName
Description ifDescr (ifEntry 2) ifIndex
Physical Layer
Network SDSL DSL network interface Network SDSL; DSL FR NAM;
Hardware Version:
hhhh-hhh
101020001
Ethernet Ethernet Port Ethernet Port; DSL FR NAM;
Hardware Version:
hhhh-hhh
101006001
Sync Data Port
S01P1
Synchronous Data
Port-1
Synchronous Data Port, Slot: 1,
Port: 1; DSL FR NAM;
Hardware Version:
hhhh-hhh
101003001
COM Communications port COM Port; DSL FR NAM;
Hardware Version:
hhhh-hhh
101004001
Frame Relay Logical Layer
FR UNI Frame relay logical
link on the DSL
network interface
For the DTE side:
Network SDSL of FR DTE;
DSL FR NAM; Hardware
Version:
hhhh-hhh
101023001
For the DCE side:
Network SDSL of FR SERVICE;
DSL FR NAM; Hardware
Version:
hhhh-hhh
Frame relay logical
link on the
Synchronous Data
Port-1
For the user side:
Synchronous Data Port of
FR DTE, Slot: 1, Port: 1;
DSL FR NAM; Hardware
Version:
hhhh-hhh
101016001
For the network side:
Synchronous Data Port of
FR SERVICE, Slot: 1, Port: 1;
DSL FR NAM; Hardware
Version:
hhhh-hhh
