Troubleshooting
8-15
9783-A2-GB20-00
July 2000
Tests Available
The following tests are available to a FrameSaver DSL unit.
Test Menu Example
main/test 9783
Device Name: Node A 05/13/2000 08:02
TEST
Network PVC Tests
Data Port PVC Tests
Data Port Physical Tests
IP Ping
Lamp Test
Abort All Tests
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Ctrl-a to access these functions, ESC for previous menu M
ainMenu Exit
Network and Data Port PVC Tests do not appear on the menu when no PVCs
have been configured on the interface. Check that both ends of the cables are
properly seated and secured.
Tests can be commanded from the OpenLane SLM system using its enhanced
Diagnostic Troubleshooting graphical interface, as well as from the menu-driven
user interface.
