8-1
9783-A2-GB20-00
July 2000
Troubleshooting
8
This chapter includes the following:
H
Problem Indicators
H
Resetting the Unit and Restoring Communication
—
Resetting the Unit from the Control Menu
—
Resetting the Unit By Cycling the Power
—
Restoring Communication with an Improperly Configured Unit
H
Troubleshooting Management Link Feature
H
LMI Packet Capture Utility Feature
—
Viewing Captured Packets from the Menu-Driven User Interface
H
Alarms
H
Trap Event Log
H
Troubleshooting Tables
—
Device Problems
—
ATM Problems
—
Frame Relay PVC Problems
H
Tests Available
—
Test Timeout Feature
H
Starting and Stopping a Test
—
Aborting All Tests
H
PVC Tests
—
PVC Loopback
—
Send Pattern
—
Monitor Pattern
—
Connectivity
