Operation and Maintenance
6-35
9783-A2-GB20-00
July 2000
Trap Event Log
The Trap Event Log displays all traps stored in the SNMP trap event log. The
following log example describes the alarm conditions that will generate an SNMP
trap for a physical interface, and for the frame relay LMIs and DLCIs. These
alarm conditions also generate Health and Status messages seen on the System
and Test Status screen.
Main Menu
→
Status
→
Trap Event Log
Trap Event Log Screen Example
main/status/event_log 9783
Device Name: Node A 05/13/2000 06:07
TRAP EVENT LOG
Total Trap Events: 4
Time Elapsed
_Since Event
_ _Event________________________________________
0d 23:59:59 Change in Frames Discarded due to Inbound Resource Errors on Sync
6d 00:01:02 DLCI 101 of Sync Data Port S01P1 frame relay link “Port-1” up.
10d 10:21:32 DLCI 101 of Sync Data Port S01P1 frame relay link “Port-1” down.
364d 11:13:14 Unit reset.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
ESC for previous menu M
ainMenu Exit
R
efresh PgUp PgDn
Up to 12 trap events can be displayed on a screen, the most current first. Page
down (PgD
n) to view less current trap events. When no trap events have been
logged, No Events in Log. appears in the Event column.
ASCII trap strings used to describe trap events are provided in the tables
contained in
Standards Compliance for SNMP Traps
in Appendix B,
SNMP MIBs
and Traps, and RMON Alarm Defaults
.
