Operation and Maintenance
6-33
9783-A2-GB20-00
July 2000
Table 6-15. ATM Performance Statistics (2 of 2)
Statistic What It Indicates
OCD Events The number of times Out of Cell Delineation (OCD) events
have been detected. An OCD event is declared when 7
consecutive cells with HEC violations are detected.
Cell Delineation State Whether the cell last received was in synchronization. Possible
values are:
H In Sync
H Out of Sync
