Table 6-13. DLCI Performance Statistics (2 of 2)
Statistic What It Indicates
H With BECN Set H The number of frames and octets sent on the selected DLCI
of the frame relay link with backward explicit congestion
notifications.
BECNs are sent to notify users of data traffic congestion in
the opposite direction of the frame carrying the BECN
indicator.
Total Rx Frames/
Rx Octets
Total number of data frames and octets (8-bit bytes) received
for the selected DLCI on the frame relay link.
H Within CIR
**
H The number of frames and octets received on the selected
DLCI of the frame relay link that were within the committed
information rate.
H Between
CIR&EIR
**
H The number of frames and octets received on the selected
DLCI of the frame relay link that were between the
committed information rate and excess information rate.
H Above EIR
**
H The number of frames and octets received on the selected
DLCI of the frame relay link that were above the excess
information rate.
H With DE Set H The number of frames and octets received on the selected
DLCI of the frame relay link with the discard eligible bit set.
H With BECN Set H The number of frames and octets received on the selected
DLCI of the frame relay link with backward explicit
congestion notifications.
BECNs are sent to notify users of data traffic congestion in
the opposite direction of the frame carrying the BECN
indicator.
H With FECN Set H The number of frames and octets received on the selected
DLCI of the frame relay link with forward explicit congestion
notifications.
The network sends FECNs to notify users of data traffic
congestion in the same direction of the frame carrying the
FECN indicator.
** Only appears for units with the SLV feature set.
