Performance Statistics
Use the Performance Statistics menu to display statistical information for a
selected interface. Statistical information is useful when trying to determine the
severity and frequency or duration of a condition.
Main Menu
→
Status
→
Performance Statistics
Physical and link layer statistics (Layers 1 and 2) are collected on the port. The
following menu shows the performance statistics that can be selected.
Performance Statistics Menu
main/status/performance 9783
Device Name: Node A 05/13/2000 06:06
PERFORMANCE STATISTICS
Service Level Verification
DLCI
Frame Relay
ATM
Ethernet
Clear All Statistics
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Ctrl-a to access these functions, ESC for previous menu M
ainMenu Exit
