Operation and Maintenance
6-22
9783-A2-GB20-00
July 2000
IP Routing Table
Use the IP Routing Table to see all the routes configured in the FrameSaver unit.
Main Menu
→
Status
→
IP Routing Table
IP Routing Table Screen Example
main/status/ip_rout 9783
Device Name: Node A 05/13/2000 06:05
Page 1 of 2
IP ROUTING TABLE
Destination Mask Gateway Hop Type Interface TTL
135.001.001.000 255.255.255.000 135.026.001.254 1 Tmp PVCMgmt1001 130
135.001.002.111 FFF.EEE.FFF.FFF 135.026.001.254 1 NMS PVCMgmt1002 130
135.001.220.000 255.255.255.000 135.042.001.254 1 Loc Ethernet 999
135.001.221.000 255.255.255.000 135.042.001.254 1 Loc COM 999
135.001.220.000 255.255.255.000 135.042.001.254 1 Loc COM 999
135.001.222.111 255.255.255.000 135.026.001.254 1 RIP Ethernet 30
135.001.222.113 255.255.255.255 135.026.001.254 1 RIP PVCMgmt1003 30
135.001.002.111 255.255.255.255 135.026.001.254 1 NMS PVCMgmt1004 2
135.001.002.111 255.255.255.255 135.026.001.254 1 NMS PVCMgmt1005 48
135.001.002.111 255.255.255.255 135.026.001.254 1 NMS PVCMgmt1006 21
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
ESC for previous menu M
ainMenu Exit
R
efresh PgDn PgUp
The table is sorted by the Destination IP address, from the lowest number to the
highest. If no routes exist, the No Routes message appears instead of routing
information.
