Network Interface Status
Network Interface Status can be viewed from the Status menu.
Main Menu
→
Status
→
Network Interface Status
Network Interface Status Screen Example
main/status/network 9783
Device Name: Node A 05/13/2000 06:04
NETWORK 1 INTERFACE STATUS
Operating Rate(Kbps): 2320
Receiver Attenuation(dB): 0
SNR Margin(dB): 15.5
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
ESC for previous menu M
ainMenu Exit
R
efresh PgUp PgDn
Table 6-10. Network Interface Status
Field
Status What It Indicates
Operating Rate
144, 192, 272, 384, 400,
528, 768, 1168, 1552,
2320
The DSL line rate.
Disconnected The line is disconnected.
Auto-rating The unit is in the process of
determining the line rate.
Receiver
Attenuation(dB)
–3, 0, +3, +6, +9, +12 The loss of signal strength of the
received DSL network signal,
assuming the far end was
transmitting at 13.5 dB.
Disconnected The line is disconnected.
SNR Margin(dB)
–64 to +63.5 dB
in 0.5 dB increments
The amount of increased noise the
system can tolerate on the DSL
network interface without exceeding
a Bit Error Rate of 10
–7
.
Disconnected The line is disconnected.
