User's Manual

Operation and Maintenance
6-9
9783-A2-GB20-00
July 2000
Table 6-5. Device Messages (3 of 5)
Message What To DoWhat It Indicates
Limit of six Login IDs
reached
An attempt to enter a new
login ID was made, and the
limit of six login/password
combinations has been
reached.
H Delete another login/password
combination.
H Reenter the new login ID.
Limit of Mgmt PVCs
reached
New was selected from the
PVC Connection Table and
the maximum number of
management PVCs has
already been created.
H Do not create the
management PVC.
H Delete another management
PVC, and try again.
Limit of PVC
Connections reached
New was selected from the
PVC Connection Table and
the maximum number of
PVCs has already been
created.
H Do not create the PVC
connection.
H Delete another PVC
connection, and try again.
Name Must be Unique Name entered for a
management PVC has
been used previously.
Enter another 4-character name
for the logical/management link.
No Destination Link
DLCIs Available
New was selected from the
PVC Connection Table, but
even though DLCIs are
available to form a
connection, no DLCIs are
available on the network
link, which is a suitable
PVC Destination.
Configure additional DLCIs for
the network link and try again.
No DLCIs available for
connection
New was selected from the
PVC Connection Table, but
all configured DLCIs have
been connected.
No action needed, or configure
more DLCIs and try again.
No DLCIs available for
connection
New was selected from the
Management PVCs option
screen, but all Link/DLCI
pairs have been connected.
Configure more network and/or
Port-1 Links/DLCIs pairs and try
again.
No DLCIs Available for
Mgmt PVC
New was selected from the
Management PVCs option
screen, but all configured
DLCIs have been
connected.
Configure more network and/or
Port-1 DLCIs and try again.
No DLCIs Defined DLCI Records was selected
from an interface’s
Configuration Edit/Display
menu, and no DLCI
Records have been created
for this interface.
Select New and create a DLCI
record.
