Operation and Maintenance
6-8
9783-A2-GB20-00
July 2000
Table 6-5. Device Messages (2 of 5)
Message What To DoWhat It Indicates
Duplicate DLCI
Number
DLCI number entered is not
unique for the frame relay
link.
No action is needed; previous
contents of the DLCI number
field is restored.
File Transfer Complete
(Seen at an FTP
terminal.)
A file transfer was
performed successfully.
Switch to the newly downloaded
software.
See
Changing Software
in
Chapter 7,
FTP Operation
.
File Transfer Failed –
Invalid file
(Seen at an FTP
terminal.)
A file transfer was
attempted, but it was not
successful.
H Try again, making sure you
type the filename correctly.
H Exit the FTP session, or
download another file.
See
Changing Software
in
Chapter 7,
FTP Operation
.
Invalid Character (
x
) A non-valid printable ASCII
character has been
entered.
Reenter information using valid
characters.
Invalid date: must be
mm/dd/yyyy
A non-valid date was
entered on the System
Information screen.
Reenter the date in the
month/day/4-digit year format.
Invalid date and/or
time
A non-valid date or time
was entered on the System
Information screen. The
date does not exist (e.g.,
February 30th).
Reenter the date in the
month/day/4-digit year format
and/or time in the
hour:minutes:seconds format.
Invalid time: must be
hh:mm:ss
A non-valid system time
was entered on the System
Information screen.
Reenter the time in the
hour:minutes:seconds format.
Invalid – Already
Active
A test was already in
progress when it was
selected.
No action is needed.
Invalid Password Login is required and an
incorrect password was
entered; access is denied.
H Try again.
H Contact your system
administrator to verify your
password.
Invalid Test
Combination
A conflicting loopback or
pattern test was in progress
when Start was selected to
start another test, or was
active on the same or
another interface when
Start was selected.
H Wait until other test ends and
message clears.
H Cancel all tests from the Test
screen (Path: main/test).
H Stop the test from the same
screen the test was started
from.
