User Guide

68
Appendix
x 3.5mm Ear Jack
x Micro-HDMI Connector
Dimensions & Weight
x Weight: under 461.5 g/16.28 oz
x Dimensions: 205 mm x 150 mm x 10.30 mm (8.36” x 6.12” x 0.41”)
Power Management (Performance)
Battery Type Capacity
Standby
Time
Video
Playback
Time
Audio
Playback
Time
Charging
time
Standard
Lithium Ion
(Li-Ion)
6,400mAh
Up to
910 hours
Up to
11 hours
Up to
95 hours
Up to
6 hours
Operating Frequency
x GPRS/EDGE 850/900/1800/1900 MHz, UMTS/HSPA+ 850/1900/
2100 MHz, LTE Band 17/Band 4 networks in North America, South
America, Europe, Africa, and Asia-Pacific where these networks are
supported
x Automatic band switching
Cautions on waterproof and dustproof functions
This product is IP57* certified according to IP code defined in the
international standard IEC60529. It is tested and certified by a test lab
facility located in Korea.
*IP57: The first digit 5 of IP57 indicates the ingress of dust at a level that
will not have a harmful effect on the operation of the unit. The second
digit 7 of IPX7 indicates that the tablet is protected against water
immersion for 30 minutes at a depth of 1 meter. The higher the number
is, the more the tablet is protected.
While this tablet has superior protection against accidental contact with
water than devices with lower IP ratings, it is NOT intended to be used
underwater or in the water.
Before using the tablet, read the followings carefully: if you use the tablet
without following cautions below, water, dust or foreign substances can
incur fire, electric shock, injury, or malfunction of the tablet.
1. Your tablet can malfunction if it is exposed to water projected at any
angle through a 6.3 mm nozzle at a flow rate of 12.5 liters per minute
for more than 3 minutes from a distance of 2.5–3 meters.
2. Water can soak into the tablet and incur malfunction if it is
submerged in water at a depth of 1 meter for more than 30 minutes.
3. Your tablet can malfunction if it is exposed to equipment for more
than 8 hours that emits dust with diameter less than 75µm.
4. All external connections must be properly covered.
5. If the speaker and/or microphone are physically damaged, this may
undermine the waterproof function and cause malfunction or a slow
down of the reaction time of your tablet.
6. Waterproof function can be undermined if external shock incurs
damage to the tablet.
7. If your tablet is exposed to liquids other than water, e.g. soft drink,
alcohol, or milk, it may become sticky in time and cause malfunction
of the tablet.
8. It is recommended that you replace the USB and earphone ports
every 12 month to maintain the waterproof integrity of your tablet.
9. The touch screen may not work if the touch screen is moist, or if you
tap the touch screen with wet hands.
10. The sound quality of your tablet can be adversely affected if your
tablet is not dried completely. It is recommended that you completely
dry your tablet before using it.
