Equipment Overview
The power inlet/cord(s) connects the PDU to the electrical power source. On metered
PDUs, the LCD displays the current load for each input feed or electrical phase per input
feed.
l One shielded RJ45 connector for Ethernet connection
l Two unshielded RJ45 connectors for SmartZone™ sensors (For a list of supported
sensors, see "Optional Accessories".)
For IEC C-20 inlet PDUs, a customer-supplied cord is used for connection to the power
source.The connection end to the PDU has an IEC C-19 plug for connection to the
PDU. The opposite end of the cord shall have a plug suitable for connecting to the cus-
tomer supplied receptacle. The cord and plug shall be rated for 20A in North America
and 16A outside of North America. The connection to the PDU should be made prior to
connecting to the power source
Model Numbering Format
This section describes the model numbering format used to identify equipment in the
PDU series.
PDU devices are numbering using one of the following formats:
l P1N-ABCDEFGHJKLM
l Q1N-ABCDEFGHJKLM
The P1N prefix indicates that the model is intended for horizontal mounting.
The Q1N prefix indicates that the model is intended for vertical mounting.
The remaining series of letters represent values as defined in the table below.
Letter What It Represents
A
any numeral, 1-8, indicating the phase wiring for the output circuit break-
ers and receptacles
B Any letter, A-F, indicating input cord configuration
CD*
Any numeral, 1-5, and any letter, A-Z, indicating input plug type and
rated voltage
