Explanations of the editable fields in the drop-down menus for Temperature, Humidity
and Analog Voltage can be found in the table below.
Defaults- Temperature, Humidity, and Analog Voltage
Scaling Factor
(Analog Voltage only)
The scaling factor is a value multiplied against the measured
Analog Voltage to produce the Input Sensor measurement.
Example: Given a measurement of 10 Volts on the input
sensor and a Scaling Factor of 100, the web UI and SNMP
interface will report a value of 10*100 = 1000 Volts as the
sensor measured value.
Note: The [Upper|Lower] [Control|Warning] Limit fields
apply to the post-scaled value.
Calibration Offset
Alters the actual reading of a sensor by the amount specified.
Example: If a Calibration offset of 6 was used and a sensor’s
true reading was 36, the indicated reading used for display
