Network-Enabled M Series Rack PDU User Manual
- 35 -
Receive Traps Settings
range of traps
Enabled (Incl. Auth Fails)
Receive traps – causes the unit to issue traps if there is
an unauthorized attempt to access the unit’s SNMP func-
tions.
The version of trap/notification can be selected from the dropdown menu under Trap Ver-
sion.
SNMP Trap Description Text Format
SNMP Traps are detected when certain events are detected. The format of the gen-
erated text messages is explained below.
NOTE: Before the text message is sent, all leading, trailing and repeated whitespace is
removed.
The SNMP trap text format is:
<snmp-trap-format> ::= <opt-timestamp-prefix> " " <opt-system-
name> " " <opt-system-location> " " <opt-contact-name> " "
<trap-kind> " " <source-name> " " <chan-no> " " <user-text> "
" <value> " " <data-type> " " <opt-timestamp-postfix>
The following table contains definitions for each parameter.
SNMP Trap Text Format
<opt-system-name> ::= <text>
Optional. When Setup -> IP Config / System
Name / Include In Trap is checked, Setup -> IP
Config -> System Name is displayed.
<opt-system-location> ::= <text>
Optional. When Setup -> IP Config / System Loca-
tion / Include In Trap is checked, Setup -> IP Con-
fig -> System Location is displayed.
<opt-contact-name> ::= <text>
Optional. When Setup -> IP Config / Contact
Name / Include In Trap is checked, Setup -> IP
Config -> Contact Name is displayed.
<opt-timestamp-prefix> ::= <text>
Optional date/time prefix. (When Setup / Prefer-
ences Timestamp Traps: is set to “Prefix”.)
<trap-kind> ::= <text>
Type of notification. Warning, Critical, Information
