Operating Instructions

12 - Read Before Using
Using the Buttons and Dials
Colours
Rapid 15
Shirts
Bedding
Wool
Rinse
Easy-care
Quick
0
500
800
10001200
1400
Start/Pause
Sportswear
Spin
Drain
Off
Cotton
Cotton
Cotton-Eco
15ºC Wash
4
5
6
3 2
1
7 8
Model NA-148VB4
Programme selection dial1.
Use this dial to choose the best
programme for the laundry. (See pages
16.)
Spin speed dial2.
Use this dial to choose the spin speed
for the programme you have selected.
The spin speeds for each of the models
are as follows (5 levels):
148VB4 and 147VB4: 500, 800, 1000, -
1200, and 1400 rpm
128VB4 and 127VB4: 500, 600, 800, -
1000, and 1200 rpm
If you select a spin speed which is
higher than the speed available (see
page 18-19), then the max. speed is
applied.
Extra Rinse/Child Lock button 3.
Press this button to select the Extra -
Rinse function. (See page 22.)
Press and hold this button for 5 seconds -
to set the child lock. The controls will be
locked but the door will not be locked.
Perform the same operation to release
the child lock. (See page 22.)
Time button 4.
Press this button to preset the time for
when the washing starts. (See page 22.)
Temperature button5.
Press this button to choose water
temperatures ranging from cold (Cld)
to 90ºC. (90ºC is available only with
the Cotton and the Cotton (Prewash)
programmes.) You can choose hotter
temperatures for whites, cottons, or
soiled laundry.
Start/Pause button6.
Press this button to start or pause the
wash programme. The button blinks if
the wash is paused.
Water cut off/low water pressure 7.
warning light
This light flashes when water is not
supplied or insufficiently supplied. (See
page 30.)
Blocked drain filter warning light8.
This light flashes when the water-drain
hose or drain filter is blocked. (See page
30.)
