High Speed Color Scanner Operating Instructions

Cleaning the Unit
29
7
Use the Roller Cleaning Paper to clean
the surface of the conveyor rollers and
exit rollers.
• Wipe the conveyor rollers and the exit rollers
from one end to the other (in the direction of
the arrow) all the way around them, as
shown in the illustration.
8
Use the Roller Cleaning Paper to clean
the surface of the free rollers.
• Wipe the free rollers from one end to the
other (in the direction of the arrow) all the
way around them, as shown in the
illustration.
9
Close the ADF door.
• Push down on both sides of the ADF door
gently until it clicks into place.
10
Clear the roller cleaning counter with
the User Utility.
• After the rollers have been cleaned, press
the [Clear Counter] button to clear the [After
Clean Roller] counter to zero on the User
Utility window.
• Refer to the User Utility Reference Manual.
Exit rollers
Conveyor rollers
Free rollers
