3-(5). Operate/release time
Sample: JW2SN-DC12V-F, 6 pcs.
Ambient temperature: 20C 68F
4-(1). Coil temperature rise
(Contact carrying current: 5A)
Sample JW1aFSN-DC12V-F, 6 pcs.
Point measured: Inside the coil
4-(2). Coil temperature rise
(Contact carrying current: 10 A)
Sample: JW1aFSN-DC12V-F, 6 pcs.
Point measured: Inside the coil
9
8
7
6
5
4
3
2
1
0
80 90 100 110 120 130
Max.
Coil applied voltage, %V
Operate/release time, ms
Operate time
Release time
Min.
Max.
Min.
Max.
x
-
x
-
100 140120 160
10
20
30
40
50
60
70
0
Coil applied voltage, %V
Temperature rise, C
85C
60C
25C
100 140120 160
10
20
30
40
50
60
70
0
Coil applied voltage, %V
Temperature rise, C
85C
60C
25C
DIN terminal sockets PCB sockets
Retaining springs
NO
14
21
BA
NC 12
NO 14
21
BA
NC 12
COIL
COM
24
COIL
11
COM
22
JW1SI JW2SI
JW1PI JW2PI
JWHFSI JWHFI
h (relay height) = 20.4 mm
Plate
Module
h = height, relay
JW1SI
JW2SI
JW1PI
JW2PI
