Datasheet

JW
2
ds_61B08_en_jw: 100811D
TYPICAL APPLICATIONS
ORDERING INFORMATION
TYPES
Standard (5A) types
High capacity (10 A) types
COIL DATA (at 20C 68F)
Contact arrangement Coil voltage, V DC Part No. Contact arrangement Coil voltage, V DC Part No.
1 Form A
5 JW1aSN-DC5V-F
2 Form A
5 JW2aSN-DC5V
6 JW1aSN-DC6V-F 6 JW2aSN-DC6V
9 JW1aSN-DC9V-F 9 JW2aSN-DC9V
12 JW1aSN-DC12V-F 12 JW2aSN-DC12V
18 JW1aSN-DC18V-F 18 JW2aSN-DC18V
24 JW1aSN-DC24V-F 24 JW2aSN-DC24V
48 JW1aSN-DC48V-F 48 JW2aSN-DC48V
1 Form C
5 JW1SN-DC5V
2 Form C
5 JW2SN-DC5V
6 JW1SN-DC6V 6 JW2SN-DC6V
9 JW1SN-DC9V 9 JW2SN-DC9V
12 JW1SN-DC12V 12 JW2SN-DC12V
18 JW1SN-DC18V 18 JW2SN-DC18V
24 JW1SN-DC24V 24 JW2SN-DC24V
48 JW1SN-DC48V 48 JW2SN-DC48V
Contact arrangement Coil voltage, V DC Part No. Contact arrangement Coil voltage, V DC Part No.
1 Form A
5 JW1aFSN-DC5V-F
1 Form C
5 JW1FSN-DC5V
6 JW1aFSN-DC6V-F 6 JW1FSN-DC6V
9 JW1aFSN-DC9V-F 9 JW1FSN-DC9V
12 JW1aFSN-DC12V-F 12 JW1FSN-DC12V
18 JW1aFSN-DC18V-F 18 JW1FSN-DC18V
24 JW1aFSN-DC24V-F 24 JW1FSN-DC24V
48 JW1aFSN-DC48V-F 48 JW1FSN-DC48V
Nominal voltage,
V DC
Pick-up voltage,
V DC (max.)
(Initial)
Drop-out voltage,
V DC (min.)
(Initial)
Nominal operating
current, mA
(10%)
Coil resistance,
W
(10%)
Nominal operating
power, mW
Max. allowable
voltage
5 3.5 0.5 106 47
530
130% V of
Nominal Voltage
(at 60C 140F)
120% V of
Nominal Voltage
(at 85C 185F)
6 4.2 0.6 88 68
9 6.3 0.9 58 155
12 8.4 1.2 44 270
18 12.6 1.8 29 611
24 16.8 2.4 22 1,100
48 33.6 4.8 11 4,400
1. Home appliances
TV sets, VCR, Microwave ovens
2. Office machines
Photocopiers, Vending machines
3. Industrial equipment
NC machines, Robots, Temperature
controllers
Ex. JW
Contact
arrangement
*Only for 1 Form A and 1 Form C type
UL/CSA, VDE, SEMKO, FIMKO, SEV approved type is standard.
Notes:
Contact capacity
Protective
construction
Pick-up
voltage
Coil insulation
class
Coil voltage
1:
1a:
2:
2a:
Nil:
F:
S: Sealed type N: Nil:
B:
Class E
insulation
Class B
insulation
DC 5, 6, 9, 12,
18, 24, 48 V
Contact material
F: AgSnO
2 type (1a)
Nil: AgNi type (1c, 2a, 2c)
1 F S N B DC5V
1. When ordering TV rated (TV-5) types, add suffix-TV (available only for 1 Form A type).
2. Standard packing: Carton: 100 pcs. Case: 500 pcs.
3. Please inquire about the previous products (Cadmium containing parts).
70% of
nominal
voltage
Standard
(5 A)
High capacity
(10 A)*
1 Form C
1 Form A
2 Form C
2 Form A
