Datasheet

DC 3-wire type
Type
Shielded type Non-shielded type
Model No.
Normally open
GX-M8A□ GX-M12A□ GX-18A□ GX-M30A□ GX-MK12A □ GX-MK18A □ GX-MK30A □
Item
Normally closed
GX-M8B□ GX-M12B□ GX- 18B□ GX- M30B□ GX-MK12B □ GX-MK18B □ GX-MK30B □
Max. operation distance (Note 2,3)
1.5 mm 0.06 in ±10 % 2 mm 0.08 in ±10 % 5 mm 0.20 in ±10 % 10 mm 0.39 in ±10 % 7 mm 0.28 in ±10 % 12 mm 0.47 in ±10 % 22 mm 0.87 in ±10 %
Stable sensing range (Note 2,3)
0 to 1.2 mm
0 to 0.05 in
0 to 1.6 mm
0 to 0.06 in
0 to 4 mm
0 to 0.16 in
0 to 8 mm
0 to 0.32 in
0 to 5.6 mm
0 to 0.22 in
0 to 9.6 mm
0 to 0.38 in
0 to 17.6 mm
0 to 0.69 in
Standard sensing object
Iron sheet 8 × 8 × t 1 mm
0.32 × 0.32 × t 0.04 in
Iron sheet 12 × 12 × t 1 mm
0.47 × 0.47 × t 0.04 in
Iron sheet 18 × 18 × t 1mm
0.71 × 0.71 × t 0.04 in
Iron sheet 30 × 30 × t 1 mm
1.18 × 1.18 × t 0.04 in
Iron sheet 24 × 24 × t 1 mm
0.94 × 0.94 × t 0.04 in
Iron sheet 24 × 24 × t 1 mm
0.94 ×0.94 × t 0.04 in
Iron sheet 45 × 45 × t 1 mm
1.77 × 1.77 × t 0.04 in
Hysteresis (Note 2) 15 % or less of operation distance (with standard sensing object)
Repeatability
(Note 2)
Along sensing axis: 5 % or less of operation distance
Supply voltage 12 to 24 V DC ±10 % Ripple P-P 10 % or less
Current consumption (Note 4) 10 mA or less
Output
<NPN output type>
NPN open-collector transistor
• Maximum sink current 200 mA
• Applied voltage: 24 V DC or less (between output and 0 V)
• Residual voltage 2 V or less
<PNP output type>
PNP open-collector transistor
• Maximum source current 200 mA
• Applied voltage: 24 V DC or less (between output and + V)
• Residual voltage 2 V or less
Utilization category
DC-12 or DC-13
Short-circuit protection
Incorporated
Max. response frequency 5 kHz 5 kHz 2 kHz 1 kHz 2.5 kHz 1 kHz 0.5 kHz
Operation indicator Yellow LED (lights up when the output is ON)
Environmental resistance
Pollution degree 3 (industrial enviroment)
Protection IP67 (IEC) IP69K (DIN), IP68 (IEC) (2 m cable length type only) , IP67 (IEC) (M12 plug-in connector type only)
Ambient temperature –25 to +70 °C –13 to +158 °F, Storage: –40 to +85 °C –40 to +185 °F
Ambient humidity 50 % RH or less (at +70 °C +158 °F)
EMC EN 60947-5-2
Voltage withstandability 500 V AC for one min. between all supply terminals connected together and enclosure
Vibration resistance 10 to 55 Hz frequency, 0.5 mm 0.02 in amplitude in X, Y and Z directions for 1.5 hours each
Shock resistance 294 m/s
2
acceleration (30 G approx.) in X, Y and Z directions for three times each
Sensing range variation
(Note 2)
Within ±10 % uctuation of sensing range at +23 °C +73 °F and rated voltage in the range of
allowable temperature and supply voltage
Material Enclosure: Brass (Nickel plated), Sensing part: PPS
Cable (except for M12 plug-in connector type)
0.44 mm
2
(0.15 mm
2
for GX-M8□) 3-core cabtyre cable, 2 m 6.56 ft long
Cable extension Extension up to total 10 m 32.80 ft is possible with 0.34 mm
2
, or more, cable.
Net weight
(Note 5)
2 m cable length type
40 g approx. 70 g approx. 90 g approx. 150 g approx. 75 g approx. 100 g approx. 180 g approx.
M12 plug-in connector type 15 g approx. 20 g approx. 45 g approx. 110 g approx. 25 g approx. 55 g approx. 140 g approx.
Accessories
Nut: 2 pcs.
Notes: 1) Where measurement conditions have not been specied precisely, the conditions used were an ambient temperature of +23 °C +73.4 °F.
2) It is the value in state where the circumference of a detection side has a metal object.
3) The maximum operation distance stands for the maximum distance for which the sensor can detect the standard sensing object.
The stable sensing range stands for the sensing range for which the sensor can stably detect the standard sensing object even if there is an ambient
temperature drift and/or supply voltage uctuation.
4) It is the leakage current when the output is in the OFF state.
5) The weight includes the weight of two nuts.
SPECIFICATIONS
Cylindrical Inductive Proximity Sensor GX-M SERIES
