Owner's Manual

EN EN

VIII

. SPECIFICATIONS

NOTE:

Weight indication

Greater than or equal to 1 kg : indicated by 0.05 kg.

Less than 1 kg : indicated by 0.01 kg.

MAIN UNIT

Model No.

EYFPA1

J JR

Motor voltage 21.6 V DC

Chuck size Single-ended □19.0 mm (3/4”)

No load speed 0 – 1900

Impact per minute 0 – 2200

Maximum torque

700 N·m

(6860 kgf·cm, 6194 in·lbs)

Torque control function operating range

Approx. 160 – 650 N·m

(1568 – 6370 k

gf·cm, 1415 – 5752 in·lbs)

Overall length

250 mm

(9-27/32”)

Weight (with battery pack: EYFB60) 3.6 kg (8.0 lbs)

BATTERY PACK (not included with shipment)

Model No. EYFB60

Storage battery Li-ion battery

Battery voltage 21.6 V DC (3.6 V/6 cells)

BATTERY CHARGER (not included with shipment)

Model No. EY0L82

Rating See the rating plate on the bottom of the charger.

Weight 0.93 kg (2.0 lbs)

Charging time EYFB60

Usable: 65 min.

Full: 85 min.
