VIII . SPECIFICATIONS
MAIN UNIT
Model EYFGA1N EYFGA2N EYFGA3N
Motor 14.4 V DC
Chuck
size
Single-ended 9.5-13 mm (3/8"-33/64")
Double-ended 12-16 mm (15/32"-5/8")
No load speed (Stage) 0-800 (80) 0-750 (75) 0-450 (45)
Torque adjustment
range
2-5.5 N·m
(0.20-0.56 kgf·m,
17.70-48.68 in·lbs)
5-7 N·m
(0.51-0.71 kgf·m,
44.25-61.96 in·lbs)
5-10 N·m
(0.51-1.02 kgf·m,
44.25-88.51 in·lbs)
Number of torque set-
ting levels
60
(In approx. 0.08 N·m
increments)
60
(In approx. 0.08 N·m
increments)
60
(In approx. 0.13 N·m
increments)
Overall length 199 mm (7-53/64")
Weight (with battery
pack: EYFB41)
1.25 kg (2.76 lbs) 1.3 kg (2.87 lbs)
Weight (with battery
pack: EYFB42)
1.5 kg (3.31 lbs) 1.5 kg (3.31 lbs)
CAUTION:
Always check the tool’s tightening torque before use.
Improper tool operation may result in excessive or inadequate tightening.
BATTERY PACK (not included with shipment)
Model EYFB41 EYFB42
Storage battery Li-ion battery
Battery voltage 14.4 V DC (3.6 V/4 cells) 14.4 V DC (3.6 V/8 cells)
BATTERY CHARGER (not included with shipment)
Model EY0L82
Rating See the rating plate on the bottom of the charger.
Weight 0.93 kg (2.0 lbs)
Charging time
EYFB41
Usable: 35 min.
Full: 40 min.
EYFB42
Usable: 50 min.
Full: 60 min.
Remote control (not included with shipment)
Model EYFA31
Battery voltage 3 V DC
Dimensions 54 mm (2-1/8") × 86 mm (3-3/8") × 10 mm (13/32")
Weight (with battery) Approximately 29 g (0.6 lbs)
