Digital Colour Imaging Systems Operating Instructions

17
Chapter 2 Basic Fax Transmission
 Number Pad Screen  Using “Redial/Pause”
z If you are using a PBX, enter the external
access number first, and then select
“Redial/Pause” before entering the fax
number.
Ex:
Enter 9 for the outside access number,
select “Redial/Pause”, and then enter the
fax number.
 Using “✱”
z This feature is available in certain countries
only.
z A “/” symbol appears when “Tone” is
changed to “Pulse” in “06 Dialling Method”.
z The standard setting for “06 Dialling
Method” is “Tone”.
Ex:
After entering 9, select “✱” to switch to tone
dialling.
 Using “Sub-Address”
z Select “Sub-Address” to enter a sub-
address destination after the fax number.
Refer to Sub-Addressed Transmission
Using Manual Dialling (see page 75).
Ex:
After entering 4, select “Sub-Address”, and
then enter the Sub-address.
3 Press the Start key.
The original(s) are stored into memory with a
file number. Then starts dialling the telephone
number.
Inserts a pause each time it
is selected. The pause is
represented by a “-”
symbol.
Used to access some
features of your PBX.
Select when entering a
sub-address number.
The sub-address is
represented by an “s”
symbol.
Select when entering
additional destinations.
z Do not select “Set” for a
single destination.
Select “Clear” to delete an
erroneous entry, one digit at
a time.
Pause symbol
Tone symbol
Sub-address symbol
