150
Chapter 5 Internet Fax
Function Parameters for Relay Stations
Program the following parameters to use this machine as a relay station in Function Parameters:
Item Required Function Parameters Explanation
1 Fax Parameters
“142 Relay XMT”
Selecting whether the machine will accept and perform G3 Relayed
transmission.
• Invalid
Machine will not accept a Relay XMT request.
•Valid
Machine will accept a Relay XMT request.
2 Fax Parameters
“143 Relay XMT Report”
Selecting how the COMM. Journal for Relayed transmission is sent to
the originator.
•Off
Does not send.
•Always
The COMM. Journal is always sent after a Relay communication is
completed or has failed.
•Inc Only
The COMM. Journal is sent if the Relay communication to the
destination has failed.
3 User Parameters
“36 Relay XMT Password”
Enter a Relay XMT Password (up to 10 characters) to be used for the
protection against unauthorized (outside) stations from accessing
your machine to relay messages to a G3 fax machine via PSTN. This
password should be given out to authorized people only.
z Program “36 Relay XMT Password” to enable this machine
to work as a relay station.
As the relay password is transmitted in the header of Email, it should
be differentiated from the Email address used by Email or Internet
Fax. A relay password pre-programmed in this way would be easy to
identify when Internet Fax is received.
4 User Parameters
40 to 49
“Relay Domain (01)” to “Relay
Domain (10)”
Register up to 10 Domain Names (up to 30 characters) that your
machine will accept Relayed transmission.
Requests to relay a message to another G3 fax machine via PSTN.
Ex: Registered Domain Names
(01): panasonic.co.jp
(02): abc.iFax.com
(03): panasonic.com
z To increase network security by protecting from third party
access to the relay station, enter a relay-permitted domain
name and an administrator Email address for every relay
station.
z If the whole domain name is left blank, Internet Fax will
receive Relayed transmission requests from all the domain
names.
