Chapter 8 Reading Reports/Lists
Reading Individual XMT Journal
Items in the individual XMT journal are listed below.
No. Item Explanation
(1) Date/Time The date and time when the individual XMT journal is printed
(2) Journal No. Journal number
(3) Communication result “OK” indicates that the communication was successful.
“Busy” indicates that the communication has failed because of busy line.
“Stop” indicates that the Stop key was pressed during communication.
“P-OK” indicates that memory overflow occurred while storing the
documents into the memory for transmission but successfully
stored document(s) was sent.
“R-OK” indicates that the Relayed XMT was successful.
“B-OK” indicates that the Batch transmission was successful.
“M-OK” indicates that the memory reception/ substitute reception was
successful.
“- -” indicates LAN transmission.
“3-digit Info Code”
indicates that the communication has failed.
Refer to Information Codes (see page 212).
In this case, the machine will print the attached report with the first
page of your document as shown on the previous page.
(4) Number of pages transmitted
or received
The 3-digit number is the number of pages successfully transmitted or received.
When the documents are stored into the memory, two 3-digit numbers will
appear. The first 3-digit number represents the number of pages successfully
transmitted. The second 3-digit number represents the total number of pages
that were attempted to be transmitted.
*************** -IND. XMT Journal- **************** Date dd-MMM-yyyy ***** Time 15:00 ********
Date/Time = dd-MMM-yyyy 00:02
Journal No. = 035
Comm. Result = OK
Page(s) = 001/001
001/001
Duration = 09:00:01
File No. = 053
Mode = Memory Transmission
Destination = 0123456789
Received ID = 0001
Resolution = Std
- PANASONIC -
******DP-XXXX ************************* - HEAD OFFICE - ***** - 201 555 1212 - ***************
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
Continued on the next page...
