Chapter 8 Reading Reports/Lists
Reading Transaction Journal
Items in the transaction journal are listed below.
No. Item Explanation
(1) Printout date The date at which the Transaction Journal printed
(2) Printout time Printout time
(3) Journal number Journal number
(4) Communication result “OK” indicates that the communication was successful.
“Busy” indicates that the communication has failed because of busy line.
“Stop” indicates that the Stop key was pressed during communication.
“JUNK” indicates that the communication was cancelled.
“P-OK” indicates that memory overflow occurred while storing the
documents into the memory for transmission but successfully
stored document(s) was sent.
“R-OK” indicates that the Relayed XMT was successful.
“B-OK” indicates that the Batch transmission was successful.
“M-OK” indicates that the memory reception/substitute reception was
successful.
“- -” indicates LAN transmission.
“3-digit Info Code”
indicates that the communication has failed.
Refer to Information Codes (see page 212).
(1)
(2)
**************** -Journal- *************************** Date dd-MMM-yyyy **** Time 15:00 ***** P.01
(3) (4) (5) (6) (7) (8) (9) (10) (11) (12)
No. Comm. Pages File Duration X/R Identification Date Time
Diagnostic
001 OK 001/002 149 00:00:52 XMT 215
dd-MMM
20:04 C8444B0577000
002 -- 001/001 151 00:00:02 XMT TEST
dd-MMM
20:07 001 STN(S)LAN
003 -- 003/003 153 00:00:20 XMT fax@nwfax1
dd-MMM
20:09 001 STN(S)LAN
004 OK 003/003 154 00:00:21 RCV fax@nwfax1.rdmg.mgcs
dd-MMM
20:10 LAN
005 OK 001 155 00:00:19 XMT 215 dd-MMM
20:11 C0542B0577000
006 634 000/003 156 00:00:00 XMT
215 dd-MMM
20:14 0800420000000
007 408 *003 00:02:14
XMT 215 dd-MMM
21:17 0040440A30080
008 JUNK 000 157 00:00:00 RCV 01234567890 dd-MMM 21:19 C800000000000
049 OK 000/001 159 00:00:07 XMT TEL XMT
dd-MMM
20:14 0800420000000
050 OK 001/001 160 00:00:16 XMT TEL XMT
dd-MMM
20:19 CB444BG577000
<< Continue >>
(13)
-PANASONIC -
*******
DP-XXXX ****************** -HEAD OFFICE - ***** - 201 555 1212- *********
(15) (14)
