Getting To Know Your Machine (For Copy & Network Scan Functions) Model No. DP-3530/4530/6030 Problem Solving Network Scanner (Option) Accessories Function with Options Before Starting Operating Instructions Making Copies Digital Imaging Systems English Others Before operating this equipment, please read these instructions completely and keep these operating instructions for future reference.
Getting To Know Your Machine Useful Office Functions Copy Fax/Email • Copy up to Ledger size. Capable of copying text/photos/ halftone originals. • Plain Paper High-speed Super G3 compatible Fax with JBIG compression when optional Fax Communication Board (DAFG600) is installed. • Quick-Scan • Quick Memory Transmission • Email Function capability when optional Internet Fax/E-Mail Module (DA-NF600) is installed.
Getting To Know Your Machine Operating Instructions Outline Getting To Know Your Machine ● Precautions (See pages 7-13) ● Quick Operation Chart (See pages 14 and 15) ● Adding Paper, Replacing the Toner Bottle, Removing a Misfed Paper and Error Codes (See pages 14-29) Before Starting ● Control Panel Key/Button/Indicator Names (See pages 31-33) Making Copies ● Operating Instructions for making copies according to Function Categories on the LCD Touch Panel Display (See pages 34-63) Function Options ●
Getting To Know Your Machine Symbols/Icons The following Symbols/Icons are used throughout this operating instructions manual.
Getting To Know Your Machine Getting To Know Your Machine Table of Contents Getting To Know Your Machine Useful Office Functions .................................................................................................................. 2 Multi-Tasking Job Table .................................................................................................................. 2 Operating Instructions Outline .............................................................................................
Getting To Know Your Machine Table of Contents Insertion/Overlay ........................................................................................................................... 56 ■ Cover .............................................................................................................. 56 ■ Page Insertion ................................................................................................ 56 ■ OHP Interleaving ..............................................................
Getting To Know Your Machine Getting To Know Your Machine Precautions ■ Laser Safety LASER SAFETY This unit employs a laser. Only qualified service personnel should attempt to service this device due to possible eye injury. CAUTION: USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
Getting To Know Your Machine Precautions For Your Safety To prevent severe injury and loss of life, read this section carefully before using the Panasonic DP-3530/4530/6030 to ensure proper and safe operation of your machine. ■ This section explains the graphic symbols used in this Operating Instructions manual. WARNING: Denotes a potential hazard that could result in serious injury or death. CAUTION: Denotes hazards that could result in minor injury or damage to the machine.
Getting To Know Your Machine Never touch a power cord with wet hands. Danger of electric shock exists. If the power cord is broken or insulated wires are exposed, contact your Service Provider for a replacement. Using a damaged cord can cause fire or electric shocks. Stop operation immediately if your machine produces smoke, excessive heat, unusual noise, or smell, or if water is spilt onto the machine. These conditions can cause fire.
Getting To Know Your Machine Precautions CAUTION Do not place a magnet near the safety switch of the machine. A magnet can activate the machine accidentally, resulting in injuries. Do not use a highly flammable spray or solvent near the machine. It can cause fire. When copying a thick document, do not use excessive force to press it against the document glass. The glass may break and cause injuries. Never touch a labelled area found on or near the heat roller. You can get burnt.
Getting To Know Your Machine For Your Safety ■ The maximum power consumption is 1.45 kW. A properly wired (grounded), dedicated, 15A, 120V AC outlet is required. Do not use an extension cord. The power cord on this machine must be used to disconnect the main power. Please ensure that the machine is installed near a wall outlet and is easily accessible. Caution Note: Unplug the power cord from the wall outlet before removing covers.
Getting To Know Your Machine Precautions Ventilation ■ The machine should be installed in a well-ventilated area to minimize the ozone density in the air. WARNING For USA FCC WARNING: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Getting To Know Your Machine ■ Key Operator Password ● The Initial Machine Modes can be checked or changed with the Function Modes, however, these modes require the Key Operator Password. For Key Operator : When setting up this machine, please consult with the authorized service provider, and decide on the Key Operator Password together, then record it and keep it in a safe place for future reference. ■ Dept. (Departmental) Code When the Department Counter function is set up, the Dept.
Getting To Know Your Machine Operation Chart ■ Quick Operation Chart 1 Turn the Main Power Switch On From (Back side of the ADF Copier) (See page 13) Original 2 Face Up COPY If set in other function mode Tray Max. 70 originals or Original Guides Adjust to the original’s width Original Guides INV LTR LGL LTR LDR ● If the original is not positioned properly, a portion of the original may not be copied.
Getting To Know Your Machine 3 4 5 COPY SIZE Select desired settings Reduction/Enlargement only (See page 36) Number of Copies (Max. 999) Adjust the Manual Exposure or Select type of Original(s) Mainly Text Text and Photo combined Mainly Photo Copy Jobs BASIC MENU Tab 2-SIDED/ORG.
Getting To Know Your Machine Operation Chart ■ Problem Solving ● Adding Paper (1550-Sheet Paper Tray 1) 1 2 3 Max Level Indicator Paper Weight: 16-24 lb Paper Capacity: 1550 Sheets (20 lb) ● Adding Paper (3000-Sheet Large Capacity Paper Tray (LCT) (Option)) 1 2 Face-Up • When using paper with one side already printed, load the paper with the unprinted side facing upward. 2 Paper Feed Tray 1 Do not touch the tray while it is moving. After tray stops, place paper neatly on the tray.
Getting To Know Your Machine 4 3 Overfill Indicator 4 Paper Capacity: 3000 Sheets (20 lb) 3 4 New Toner Bottle 5 1 Cap 6 2 8 Empty Toner Bottle 10 to 15 times Shake the new Toner Bottle well to loosen the contents. ATTENTION ● For optimum copy quality it is recommended that only Panasonic Brand toner is used in the copier. Store toner in a cool dark area with low humidity. Do not unseal the toner bottle unless you are ready to use it.
Getting To Know Your Machine Operation Chart ■ Problem Solving (Common Operation) ● Replacing the Staple Cartridge (Common Operation) (When optional Finisher is installed.) 1 DA-FS330 Add Staples Replace the Staples Case as following procedures.
Getting To Know Your Machine 2 3 Check the operation 4 Number of Copies (Max. 999) 4 5 6 2 Tape New 1 Empty 7 Staple Cartridge 10 For DA-FS330: When the Staple is jammed ● The following message will be displayed on the Touch Panel Display: "Can Not Complete Confirm Staple Unit" 4 5 Jammed Staple 3 Jammed Staple 2 2 1 1 3 6 7 Close the Staple Cover.
Getting To Know Your Machine Operation Chart ■ Problem Solving (Continued) ● 1-Bin Saddle-Stitch Finisher (DA-FS355A) 1 2 8 Tape Stapler Unit Blue Mark Finisher Front Cover 7 3 1 9 Staple Cartridge 2 Stapler Unit ● Removing a Misfed Paper (Locations) DA-FS330 DA-FS355 DA-FS355A DA-FS600 J DA-FS605 H D C E I F B G A Misfed Location Indicator ● Indicates to open each cover, check and remove any misfed paper.
Getting To Know Your Machine 4 5 Staple Cartridge 6 Empty Staple Case 10 7 New Staple Case When the Staple is jammed ● The following message will be displayed on the Touch Panel Display: "Can Not Complete Confirm Staple Unit" Finisher Front Cover ● User Error Codes (U Code) U20, U21 U32 U4, U12 U30 U9 U6 U35 U13 U1 U7 U31, U33, U34 Code U1 U4 U6 U7 U9 U12 U13 U15 U16 Check Points Front Cover is open. Finisher is separated from the machine. Right Cover is open. Right Lower Cover is open.
Getting To Know Your Machine Operation Chart ■ Problem Solving (Continued) ● Removing a Misfed Paper (Paper Entry Area) 1 2 Right Cover ● Removing a Misfed Paper (Paper Transport Area) 1 Misfed Paper 2 Transport Release Lever ● Removing a Misfed Paper (Paper Exit/Fuser Area) 1 2 Exit Cover 6 Magnet 7 Exit Cover Heat Roller Cover ● Removing a Misfed Paper (Reverse Area) 1 2 Left Cover 22
Getting To Know Your Machine 3 4 5 Close the Right Cover.
Getting To Know Your Machine ■ Problem Solving (Continued) ● Removing a Misfed Paper (Automatic Duplex Unit (ADU)) 1 2 Transport Release Lever 6 7 Knob 5 (Left) Automatic Duplex Unit ● Removing a Misfed Paper (i-ADF) 1 ADF Cover 2 Inner Cover 6 Misfed Paper 7 2 1 Exit Guide ● Removing a Misfed Paper (System Console) 1 2 Right Lower Cover When the optional System Console (DA-DS603/DS604) is installed.
Getting To Know Your Machine 3 4 5 6 Knob 5 (Right) Knob 5 (Centre) Automatic Duplex Unit 8 9 Push and turn 3 ADF Tray 4 5 Green Labelled Tab Misfed Paper 6 Exit Guide 8 9 3 4 ADF Cover 5 Right Lower Cover 25
Getting To Know Your Machine ■ Problem Solving (Continued) ● Removing a Misfed Paper (Large Capacity Paper Tray) (Option) 1 2 Door Misfed Paper Misfed Paper Latch When the optional Large Capacity Paper Tray (DA-MA301) is installed. Hold the latch and slide the large capacity paper tray to the right. ● Removing a Misfed Paper (2-Bin Finisher) (Option) 1 2 Finisher Misfed Paper When the optional 2-Bin Finisher (DA-FS600/605) is installed.
Getting To Know Your Machine 3 Door 4 Latch 3 Punch Cover 4 5 Misfed Paper 6 Punch Cover 8 9 Finisher Upper Cover 3 4 5 Misfed Paper Push and Turn Saddle Exit Cover 6 8 27
Getting To Know Your Machine ■ Problem Solving (Continued) ● Removing a Misfed Paper (2-Bin Finisher) (Option) 1 2 Upper Cover Misfed Paper When the optional 2-Bin Finisher (DA-FS330) is installed. 6 7 Knob B Stapler Cover When the misfed paper is not found: ● Removing a Misfed Paper (1-Bin Saddle-Stitch Finisher) (Option) 1 2 Misfed Paper Finisher When the optional 1-Bin Saddle-Stitch Finisher (DA-FS355A) is installed.
Getting To Know Your Machine 3 4 5 Finisher Guide Knob A 6 Misfed Paper 8 Finisher Entry guide When paper cannot be removed: 9 Trash Box 3 4 5 Finisher Upper Cover Upper Cover 3 4 5 6 Stitch Tray Finisher Front Cover Finisher 8 Finisher 29
Before Starting Energy Star As an ENERGY STAR® Partner, Panasonic has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. This voluntary program specifies certain energy consumption and usage standards. This product will automatically “power down” after a specified period of non-use. The use of this ENERGY STAR® compliant product will reduce energy consumption and ultimately benefit the environment.
Control Panel 2 3 4 5 6 7 Before Starting 1 DP-6030 10 ORIGINAL COPY SIZE SIZE Keys Keys No. 1 2 3 4 5 6 7 8 9 10 8 9 Touch Panel Display Keypad START Key Contents COPY Key ● To use the unit as a photocopier. ENERGY SAVER Key ● Saves power while the copier is not in use. INTERRUPT Key ● Interrupts other copy or print jobs while making copies. FUNCTION Key ● Use when changing the paper size, initial function values (default values) and key operator settings.
Before Starting Touch Panel Display DP-6030 6 7 1 2 3 4 5 14 8 9 10 11 12 13 27 26 25 24 23 15 16 17 18 22 21 20 19 Job Status Indicator Ex.: Copying 3 sets. The Indicator displays the progress of a job task as follows: 0/3 → 1/3 → 2/3 → 3/3 When the Department Counter function is set up, the departmental Identification Code input screen is displayed on the Touch Panel Display.
No. Contents See Page 1 Warning Indications : Add Toner : Add Paper 2 Original Icon — 3 Original Size Indication — 4 Multi-Size Feeding / Job Build and SADF Mode Indication 5 Rotate Mode Indication — 6 Number of Copies / Original(s) — 7 Machine / User Error Code Indication (E1-01, U13, etc.
Making Copies Basic Menu ■ Copying the Same Size Originals (1:1) Copy size is automatically selected. 1 2 or 100% If set in other function mode If original size is not detected ■ Positioning Original(s) On the i-ADF On the Platen Note 1) Once after setting originals , pressing Start button, do not press originals as it may cause original jam. Note 2) When originals with clipped or stapled, take off clips or staples, then set originals neat.
3 4 Adjust the Manual Exposure or Making Copies Select type of Original(s) Mainly Text Text and Photo combined Number of Copies (Max. 999) Mainly Photo When copying a thick Booklet, open the ADF and verify that the ADF Hinge was returned to original position if the rear of the ADF was raised. ■ Copying on Heavy Paper (Post Cards, etc.) (35 lb max.
Making Copies Basic Menu ■ Copying with Preset Ratios (Reduction/Enlargement) 1 Letter 2 or or Ledger Ledger If original size is not detected Letter ■ Proof Copying Allows you to make one proof set, before proceeding to copy a large multi-set with various settings. 100 1 1 2 or 2 Proof copy Select Copy Job settings Multi copy ■ Tandem/Remote Copying Requires installation of optional Hard Disk Drive (DAHD60), Network setup (See pages 71, 78 and 79) and Parameter registration.
3 The Correct ratio is automatically selected. 4 Reduction and enlargement ratios (%) COPY SIZE Legal Letter-R Invoice-R 77 65 50 100 79 61 100 100 65 155 129 100 Making Copies ORIGINAL SIZE Ledger Ledger 100 Legal 121 Letter-R 129 Invoice-R 200 Number of Copies (Max. 999) 3 4 5 If the Proof copy is OK, the remaining number of sets will be printed. or If the Proof Copy is NG, again, place the originals back on the ADF (or Platen) and try again. Number of Copies (Max.
Making Copies Basic Menu ■ Tandem/Remote Copy Settings (Registration 1) Input the Key Operator ID Code if required. 1 4 Input ID Code (4-digit) 7 ∗ By default, the key name will be up to 15 characters of the station’s name. Enter the key name∗ (up to 15 characters). ■ Tandem/Remote Copy Settings (Registration 2) 1 If installing the machine on a Network with a different subnet mask, you must first register it before being able to use the Tandem/Remote Copying function. 5 2 6 IP Address∗ Ex: 123.
2 3 5 Making Copies 4 6 7 Scroll to 08/10 Machine name (up to 15 characters) Button Names on the QWERTY Keyboard To input upper case letter(s). To move the cursor (_) to the left or right side. To input numbers and/or symbols. To erase the character before the cursor. 3 4 5 Scroll to 05/05 7 Input ID Code (4-digit) 8 Enter the machine and key name, same as the Registration procedures above.
Making Copies Basic Menu ■ Job Queue 1 Refers to a list of jobs waiting to print, delete or change of priority (only for print job). Job 3 Job 1 Job 1 Job 2 4 ∗∗ Job 2 Deleted Job 3 Select the job(s)∗ you wish to delete Select the job(s) ∗ You can select to delete multiple/all jobs. ∗∗ Priority can be selected for print jobs only when the optional HDD is installed. ■ Completion Notice A Job Completion Notice via a pop up screen on the Desktop of your PC when the Copy Job is completed.
2 3 4 5 Making Copies Input password (4-digit) 6 2 times 3 4 5 Select the desired PC Address NOTE Number of Copies ● This Completion Notice is available only when connected to the Network. To reset the Completion Notice, press the CANCEL button.
Making Copies 2-Sided/Original ■ 1-Sided 2-Sided, 2-Sided 1-Sided Copy 1-Sided, 2-Sided 2-Sided Copy 2-Sided Copy 1 2-Sided 2 1-Sided Copy or 2-Sided Reduction/ Enlargement only 2-Sided Copy (1 ■ Book 2 Copy only) 2-Sided Copy Book 2-Sided Copy 1 (1st Page BLANK) Blank Page 2 Platen Ex : Ledger size original Book Mark∗ Ledger Letter Ledger (1st Page IMAGED) ∗ Center book by length and width according to center marks only for Ledger size.
4 Bind position 5 Number of Copies or or Making Copies 3 4 or When clearing the 2-Sided Copy: 6 From Platen: When "Last Original?" message is displayed. Ex: 2 originals Touch "NO" button. Place next original on the platen. 3 Press Start Key. 4 Touch "YES" button. or 4 or Original format Copy format 3 4 5 Number of Copies or or 6 When "Last Original?" message is displayed. Ex: 2 originals Touch "NO" button. Place next original on the platen. 3 Press Start Key. 4 Touch "YES" button.
Making Copies 2-Sided/Original Copy ■ 2 Page Copy Copying two facing pages or a Ledger size original on two separate Letter size sheets. 1 2 Platen Example: Ledger size original Ledger Letter Ledger ■ N in 1 Copy From two/four/six 1-Sided originals, side by side, to 1-Sided pages. ● 2 in 1 Copy ● 6 in 1 Copy 2 3 4 5 6 2 ● 4 in 1 Copy 1 1 1 1 2 3 4 5 6 2 1 2 3 4 or 3 4 6 ● 2-Sided Copy From 4/8/12 1-Sided originals, side by side, to 2-Sided copies.
4 5 When "Last Original?" message is displayed. Ex: 2 originals Touch "NO" button. Place next original on the platen. 3 Press Start Key. 4 Touch "YES" button. Number of Copies Copy Format Making Copies 3 or 3 4 ∗ N in 1 mode Original direction 5 Copy layout 6 ex. 2 in 1 or or Reduction/ Enlargement only or or When 2 in 1 copying with different original size, select desired copy size with COPY SIZE Key (not PAPER TRAY button on the LCD Touch Panel). ● Copy is automatically reduced.
Making Copies 2-Sided/Original Copy ■ Multi-Size Feeding Use this function when copying mixed Ledger/Letter size originals using the ADF. Original size can be detected automatically then can be copied full size (1:1) or same size.
4 3 4 Making Copies Number of Copies 5 6 3 Number of Copies Place the next original within 5 sec. of last ejected copy. If “Another Original? YES or NO” message is displayed, touch the “NO” button. 3 4 Select Sorting/Finishing settings 5 Number of Copies (ex. 5) 6 Place the next original within 5 sec. of last ejected copy. (30 sheets) or or etc. If “Another Original? YES or NO” message is displayed, touch the “NO” button.
Making Copies Sort/Finish ■ When using Sort Mode Copy is stored on the Tray. Rotate-Sort Rotate-Group 1 Sort 2 Non-Sort 1 1 1 1 1 3 1 Multiple copy sets are sorted automatically. Multiple copy sets are sorted automatically and stacked in alternate direction (rotate). (Letter size only) Shift-Sort Shift-Group 1 1 1 2 When optional Finisher is installed. Offset stacking using electronic sorting When optional Finisher is installed.
2 3 Making Copies 1 or Number of Copies Sort mode or or or Staple Position ex. Top left corner ADF When the optional Finisher (See pages 82 and 83) is installed, this screen will change as follows: For DA-FS330 or Platen or For DA-FS600/FS605 or or For DA-FS355A or or ● Overflow oF When overflow oF indicator appears on the display, remove excess copies from the bin.
Making Copies Zoom/Effects ■ Zoom Copies with variable zoom ratios from 25 % to 400 % in 1 % increments. 25% 1 2 400% or ■ Auto Zoom The copy Zoom Ratio adjusts automatically to the selected paper size. 1 2 Opening the ADF Fit to paper length or width Fit to paper length and width ■ Edge Creates a blank edge. 1 2 or ■ Book Eliminates dark inner binding shadows.
3 Same vertical and horizontal ratio Different vertical and horizontal ratio 4 or or or Keypad 25% - 400% or Number of Copies Making Copies 25% - 400% or or Keypad 3 4 5 Paper Size (Paper Tray) Fit to paper length or width Fit to paper length and width 3 Same vertical and Different vertical and horizontal void value horizontal void value Number of Copies 4 or 5 - 99 mm or or or Keypad 3 5 - 99 mm or Number of Copies or Keypad 4 5 - 99 mm or Number of Copies or Keypad NOTE
Making Copies Zoom/Effects ■ Margin 1 Shifts image to right, left, up or down. 2 or ■ Centering Copy image can be centered automatically on selected paper. 1 2 Opening the ADF ■ Image Repeat Creates continuous copy image on one sheet. Minimum original size: 20 x 20 mm 1 2 Opening the ADF The dotted line can be set to “None” or “Print” by Function mode (See page 67). ■ Inverse Negative/Positive image can be created for special effects.
3 4 Number of Copies 5 - 99 mm 3 or or Keypad Making Copies Margin area If a part of the copied image is missing when using the Margin mode, change the Margin Reduction setting to Yes.
Making Copies Zoom/Effects ■ Stamping (Page Numbering) Page numbers can be automatically stamped on each page. 1 2 ADF only∗ -1- 1/8 The page numbering format can be changed in function mode. Default format is "-n-". (See page 67) ■ Stamping (Date Stamp) The date can be automatically stamped on each page. 1 2 ADF only∗ 01/05/2003 ■ Stamping (Issue Number Stamping) An issue number can be automatically stamped on each page.
4 ORIENTATION Stamping position Number of Copies (Max. 999) Stamping start page From 1, 2 or 3 or From 3rd page From 2nd page From 1st page 3 ● Multiple copy sets will be sorted automatically. 4 ORIENTATION Stamping position Number of Copies (Max. 999) Changing the stamp date or ● Multiple copy sets will be sorted automatically. 3 4 ORIENTATION or Stamping position Stamping the Issue Number or Keypad Number of Copies (Max. 999) ● Multiple copy sets will be sorted automatically.
Making Copies Insertion/Overlay ■ Cover 1 Adds Cover Page(s) to copies. Original Blank page 1 Blank page 2 1 + 2 ADF only Original Copied page Copied page 1 Copied page 2 1 3 + 4 2 3 4 ■ Page Insertion 1 Inserts Blank/Copied pages between copies. Original Blank page 2 Blank page + Original ADF only Copied page Insertion Insertion + Copied page 2 ■ OHP Interleaving 1 Inserts Blank/Copied pages between OHP film.
3 4 Blank Number of Copies (Max. 999) Paper Size∗ Paper Tray Making Copies Cover Page mode Cover (Front) Cover (Front+Back) Copy 3 4 Page Insertion mode Blank Number of Copies Set the insert page position with (Max. 999) Keypad∗∗ If selecting other position, move the sheet with / button, then set the insert page position with Keypad Paper Size∗ Paper Tray Copy 3 5 5 4 Load OHP film onto the Sheet Bypass OHP Interleaving mode Blank Paper Size∗ Paper Tray Number of Copies (Max.
Making Copies Insertion/Overlay ■ Overlay Overlays a second image onto the first by using a second original. 1st-page 1 2 or ■ File Edit Up to three∗ editing functions available in the Form Overlay feature. ∗ : To Add a new file∗ (HDD = Max. 5 files) ∗ : To Erase a registered file ∗ : To Change the title of a file 1 2 3 ∗∗ or Select a file ∗ One image file can be registered. (Register only) ∗∗ With the optional Hard Disk Drive (DA-HD60) installed, up to 5 image files can be registered.
4 Density for 1st page image or 5 Number of Copies (Max. 999) 4 Select the overlay image to store From Platen: into memory for later use. Same procedures as for Form Overlay or 5 6 7 REGISTER Density for registered image ERASE File Name To cancel the registration, touch "CANCEL" button. or 4 4 FILE NAME EDIT 3 Enter the file name 4 Select a file 5 Number of Copies (Max. 999) From Platen: If “Another Original? message is displayed, touch the "YES" or “NO” button.
Making Copies Other Features ■ Job Memory Five Copy Jobs can be stored in Memory (M1 to M5) for recall at a later time. To store a job in memory 1 2 Set up the copy job to be stored. NOTE: When the M5 Key is used, the Double Exposure Mode should be set to "Off" in the Copier Settings "19 Double Exposure". (See page 67) M1, M2, M3, M4, M5 (See NOTE) ■ Double Exposure From 2-Sided originals to 1-Sided 2 in 1 copies (side-by-side image).∗1 Original Size: Maximum Invoice 1 2 Copy Size: Letter-R ex.
To recall a job stored in memory 1 2 3 or M1, M2, M3, M4, M5 Making Copies Number of Copies (Max. 999) (See NOTE on page 60) 3 4 5 NOTE If “2: NO” is selected, the machine will start copying only scanned original. Number of Copies (Max. 999) 7 The following steps, illustrate how to make multiple copies when the Sort Mode is selected. (See page 48) 1: YES 2: NO NOTE Continues to copy another original, repeat steps 1 and 3- 2 to step 6. Starts making copies.
Making Copies Other Features ■ Skyshot Mode Skyshot allows copying a manuscript without generating dark borders even if the Platen Cover or ADF is opened. Two types of Skyshot modes can be selected: 1) Digital Skyshot Mode : The scanning area (size) is not pre-determined. 2) Manual Skyshot Mode : The scanning area (size) is pre-registered into memory (M1 and M2) in advance. Digital Skyshot Mode The Digital Skyshot has 2 modes ( copy or copy ). The default setting of Digital Skyshot Mode is “Freeshp”.
Manual Skyshot Mode ● Set 07 Manual Skyshot Mode in Copier Settings first. (See page 67) 1 2 3 Making Copies Platen UpperLeft Corner Number of Copies (Max. 999) Custom size∗ ∗ Default M1/M2 size can be changed in the Function mode. (See page 74) 3 4 5 6 Select Function or Job Waiting List can be confirmed with Job Queue. (See page 40) Scanning is completed ■ Interrupt Mode This mode can interrupt other copy jobs while making copies/printing.
Function ■ Using Function Modes to Change the Initial Copy Modes Options General Settings Copier Settings Printer Settings Fax/Email Settings Scanner Settings Input Identification (Key Operator ID) Code General Settings for Key Operator Copier Settings for Key Operator General Settings: Printer Settings for Key Operator Fax/Email Settings for Key Operator Changing the Initial Machine Modes ● Power On Default mode, Manually add toner, etc.
Copier Settings: Changing the Initial Copy Modes ● Default function of each copy mode (See page 67) For Key Operator: Paper size priority, Original mode, Contrast, Job Build and SADF mode, Original size of Manual Skyshot mode, etc.
Function ■ General Settings Screen No. Modes Initial Setting Function 00 Power On Default Mode Selects mode. ● COPY, PRINTER, SCANNER∗, FAX∗ COPY 01 Manual Add Toner Adds toner manually. ● Off, On Off 02 Sort Memory Status Indicates the sorting memory status. ● Off, On Off 03 Departmental Counter Indicates the department counter. Consult with an authorized service provider 04 Key Operator Mode Input the Key Operator ID Code.
■ Copier Settings Modes 00 Margin Value Default Selects the margin shift value. ● 5 mm, 10 mm, 15 mm, 20 mm 10 mm 01 Edge Value Default Selects the edge width. ● 5 mm, 10 mm, 15 mm, 20 mm 5 mm 02 Book Value Default Selects the book void width. ● 15 mm, 20 mm, 25 mm, 30 mm 20 mm 03 Margin Reduction Def. Selects the reduction ratio in margin mode. ● No, Yes No 04 2-Sided Mode Default Function sets the duplex priority mode.
Function ■ Scanner Settings Screen No. Modes 00 Original Mode Default Sets the original setting. ● Text, T/P (Text/Photo), Photo T/P 01 Compression Mode Def. Sets the default compression mode setting. ● MH, MR, MMR, JBIG JBIG 02 Resolution Default Sets the default resolution setting. ● 150dpi, 300dpi, 600dpi 600dpi 03 Job Bulid And SADF Mode Sets the SADF mode setting. ● No, Yes No 04 Bind Edge 2-Side Orig. Sets the bind position, 2-Sided original setting.
■ Printer Settings 01/04 Modes 00 Number Of Prints Sets the initial number of prints. ● 1 ~ 999 1 01 Paper Size Sets the paper size setting. ● A3, B4, A4, B5, A5, LEDGER, LEGAL, LETTER, INVOICE, 8 x 13, 8.5 x 13 LETTER 02 Paper Tray Sets the Paper Tray setting. ● Auto, Bypass, Tray 1, Tray 2, Tray 3, Tray 4, LCT Auto 03 Print Direction Sets the print direction setting. ● Portrait, Landscap (Landscape) Portrait 04 Auto Tray Selection Sets the auto tray setting.
Function For Key Operator ■ General Settings Screen No. Modes 00 Paper Size Sets the paper size of each paper drawer.∗ ● Ledger, Legal, Letter, Letter-R, Invoice, A3, B4, A4, A4-R, B5, B5-R, A5, 8 x 13, 8.5 x 13, FLS2, AUTO∗∗ Consult with an authorized service dealer 01 Auto Reset Time Selects the Control Panel reset time. ● None, 30 sec., 1 min., 2 min., 3 min., 4 min. 1 min. 02 Power Save Mode Timer Sets the Energy Saver mode and time.
■ General Settings Screen No. Modes Initial Setting Function 15 Fold Position (A3/LDR) ● -4.0 - +4.0 mm 0.0 mm 16 Fold Position (B4) ● -4.0 - +4.0 mm 0.0 mm 17 Fold Position (A4/LTR-R) ● -4.0 - +4.0 mm 0.0 mm 19 Language Sel. Priority Selects the display message language. ● Off, On Off 20 Date Time Setting Sets date time registered. ● Month, Day, Year, Time 21 Weekly Timer Sets the weekly On/Off timer. 22 DHCP Default Sets the DHCP.∗ ● No, Yes 23 TCP/IP Address Sets user IP address.
Function For Key Operator ■ General Settings Screen No. 07/10 08/10 09/10 NOTE Modes 30 Sleep/Shutdown Select Selects the Sleep/Shutdown mode. ● Sleep, Shutdown 31 Print General Settings Sets the print of general function. ● Stop, Start 32 Corona Wire Cleaning Sets the corona wire cleaning. ● Off, On 33 MAC Address Indicates the MAC address. 34 Address Book Group ID Inputs group ID for address book. ● 0 ~ 99 35 Tandem User Parameter Inputs parameter of user machine.
■ General Settings Screen No. Modes Initial Setting Function Sets the Paper Tray for special paper (ex: colored). ● None, Tray 1, Tray 2, Tray 3, Tray 4, LCT, Bypass None 46 Special Paper Tray 4 Sets the Paper Tray for special paper (ex: colored). ● None, Tray 1, Tray 2, Tray 3, Tray 4, LCT, Bypass None 47 Special Paper Tray 5 Sets the Paper Tray for special paper (ex: colored).
Function For Key Operator ■ Copier Settings Screen No. 02/05 Modes Initial Setting Function 06 Interleaving Default Selects OHP interleaving paper ● Blank, Copy Blank 07 Page Insertion Default Selects page insertion ● Blank, Copy Blank 08 Cover Mode Default Selects cover paper ● F, Blank, F, Copy FB, Blank, FB, Copy (F: Front, FB: Front + Back) F, Blank 09 Job Build And SADF Mode Enables or disables the use of SADF function.
■ Printer Settings Modes 00 Job Completion Time Sets the job completion time setting. ● 1~ 999 sec. 180 01 Page Protection Compress automatically then printout. ● Off, On Off 02 Error Page Print Sets the error page printout. ● Off, On Off 03 Spool Function Sets the spool function. ● Off, On On 04 Text Print Prints text page only. ● Off, On On 05 PS Configuration Print Prints the PS status page. ● Stop, Start Start 06 Printer Settings Print Prints the printer status.
Function Examples ■ Changing the Auto Contrast Setting You can select whether to automatically adjust the copying density for Text and Photo originals. 1 2 3 Scroll to 02/05 ■ Changing the Paper Size The Paper Trays are designed to accommodate Invoice, Letter, Letter-R, Legal and Ledger Size paper. 1 2 6 3 7 8 Paper Tray Paper Size Tray 2 only Only 3 Paper Sizes (Letter, A4, and B5) will be available when selecting Tray 1. ■ Weekly Timer Key Operator can administer the On/Off weekly timers.
4 5 or 5 Function 4 6 ID Code (4-digit) 12 LTR a LTR LDR 11 LGL 10 b INV Pull out the Paper Tray Adjust the Paper Guides ( a / b ) Note: It is recommended that the paper guide ( b ) is fixed in place with screws. Consult an authorized service provider for details on how to fasten the guide. 4 Change the Paper Size Indicator For Tray 2: Change the position of the Paper Size Indicator to display and to automatically select the paper size loaded in the tray.
Function Examples ■ Department Counter The Department Counter feature can limit the number of copies, administer counters and Identification Code numbers for each department. (Maximum Number of Departments: 300) Contact your authorized service provider to enable the Department Counter feature. 1 2 3 6 For Total Counter For Identification Code or or Displays the sum of all the active department counters. Prints all the active department counters.
4 5 6 Scroll to 03/10 ID Code (4-digit) For Department Counter For Maximum Prints Clear the counter (8-digit) to “0” Select Page Select Department Maximum Number of Copies (8-digit) Select Page Select Department 4 5 ID Code (4-digit) 7 8 Turn the Power Switch on the Left Side of the machine OFF and ON. ∗ When clearing the IP address, press the " " key to move to the next segment of the IP address (∗∗∗.∗∗∗.∗∗∗.∗∗∗) and press the Clear key.
Function Combined Function Table Others INSERTION/ OVERLAY ZOOM/ EFFECTS SORT/ FINISH 2-SIDED/ORIG.
Accessories Components ■ The DP-3530/4530/6030 is a digital photocopier which can produce images with great clarity. Furthermore, its copying functionality can also be greatly enhanced by the addition of the following options and supplies. We hope you find that the wide ranging capabilities will make your office-place more productive and efficient. Image Memory (DA-SM16B/64B/28B) ● 16/64/128 MB ● To increase the memory capacity for electronic sorting.
Accessories Finisher 1. Components DA-FS600/FS605 DA-FS355A Punch Unit (Option: DA-SP31) For punching 3 holes on copies. Bin 1 Bin Saddle Stitcher Tray When using the Booklet copy mode (see page 44). 2 Bin Saddle Stitcher Tray (DA-FS605) When using the Booklet copy mode (see page 44). Punch Unit (Option: DA-SP41) For punching 3 holes on copies. 5.
DA-FS330 2. Operation 1 Bin (See page 48) 3. Replacing the Staple Cartridge 2 Bin Letter size only Electronic Shift Stapling (See pages 18-21) 4. Bin Capacity (See pages 92 and 93) 4 5 Punch Unit Front Cover 3 4 5 Return the finisher to original position. 3 4 5 Dispose the punch hole residue.
Network Scanner (Option) Registering your PC/Document Scanning ■ Registering your PC When the Panasonic Document Management System (PDMS) included on the CD-ROM is installed, start the Panasonic Communication Utility and, register your PC by setting the network scanner. 1 Right-click on the icon. Select Scanner Configuration.... ■ Document Scanning When the Panasonic Document Management System (PDMS) is installed and configured on your PC, document(s) can be scanned from the DP-3530/4530/6030 to PC.
2 3 Select “Auto Registration”. Set the PC and Key Name to be saved on the machine. When the DP-3530/4530/6030 is installed on a different subnet mask∗ of the network (LAN), Select "Add Device" then, register the machine by following the steps below. 3 Click OK. Right-click on the Panasonic Communications Utility icon, and select one of the Scanner Reception Notifications (Pop up Display or Icon Display). NOTE: ∗ Consult your system administrator for detail of your subnet mask.
Problem Solving Troubleshooting Check Action Unit Does Not Operate Does the display light? Check if the Power Switches (Main Power Switch on the back and Power Switch on the Left Side of the machine) are turned ON and if the power cord is plugged into the AC outlet. Does the Energy Saver key flash (or light) and displays are turned OFF? (See page 62) Press Energy Saver key on the control panel. Does any of the U## codes and messages appear on the display? (U1, U4, U6, U7, U11....etc.
Check Action Marked Copies Is the copier Platen Glass or Platen Sheet dirty? Clean the Platen Glass or Sheet. (See below) Is the original an OHP film or a dark original? Cover the original with a sheet of white paper before copying or lighten the exposure setting. ■ If the measures outlined above do not solve the problem, call your Service provider. Copier Care Platen Sheet Platen Glass/Platen Sheet Wipe marks off with a cloth and a neutral detergent. Wipe again with a dry cloth.
Problem Solving Replacing the Battery/Set the Date and Time The copier has an internal battery (Product No.: CR2032) which maintains the date and time. In the event the battery requires replacement, the following message will be displayed. 1 2 Data LED Turn the Power Switch on the Left Side of the machine to the OFF position and open the Front Cover. Remove a Screw and Holder. CAUTION Keep button batteries and small parts out of reach of children to prevent chocking or poisoning.
3 4 Used Data LED 1 New 2 5 Turn the Power Switch on the Left Side of the machine to the ON position and close the Front Cover. Reinstall a Holder and Screw. 3 4 5 ID Code (Department Code) 6 7 Month, Day, Year, Time Time Problem Solving Month/Day/Year/Time CAUTION denotes hazards that could result in minor injury or damage to the machine. ● THIS PRODUCT CONTAINS A LITHIUM BATTERY. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE.
Others Specifications ■ DP-3530/4530/6030 (Copier) Type Semi Console Platen Type Fixed Acceptable Originals Sheets, Books (max. Ledger) Copying Method Laser Electrophotography Fixing Method Heat Roller Fixing Imaging Method Dry-Type Two components imaging Resolution Maximum: 600 dpi Operation Panel Touch Panel Display Maximum Copy Size Ledger - Invoice via Paper Tray Void Area Max. 0.2″ (5 mm) Warm Up Time DP-4530/6030 : Approx. 180 seconds (68°F/20°C) DP-3530 : Approx.
■ i-ADF (Standard) Tray Capacity Maximum 70 sheets (20 lb: 75 g/m2) Paper Size Invoice/Letter/Legal/Ledger Paper Weight 14 – 28 lb (50 - 105 g/m2)/1-sided 17 – 28 lb (64 - 105 g/m2)/2-sided Electrical Requirements Supplied from copier Dimensions (W × D × H) 23.6 × 23.0 × 5.9 in (600 × 583 × 151 mm) Weight 32 lb (14.
Others Specifications ■ 2-Bin Finisher (DA-FS600) Mode 1 Bin and 2 Bin Non-sort/Sort/Staple Paper Size 1 Bin and 2 Bin Paper Weight Invoice/Letter/Letter-R/Legal/Ledger 16 - 35 lb (60 - 135 g/m2): Non-sort mode Paper Capacity 1 Bin and 2 Bin Maximum: 1000 sheets / 30 set (Stapling mode) Staple Paper Size Letter/Letter-R/Legal/Ledger Paper Weight 17 - 21 lb (64 - 80 g/m2) Capacity 2-50 sheets: Letter (20 lb: 75 g/m2) 2-30 sheets: Letter-R/Legal/Ledger (20 lb: 75 g/m2) Point Rear 1/Front 1/Middle
■ 2-Bin Finisher (DA-FS330) Mode 1 Bin 2 Bin Paper Size 1 Bin 2 Bin Paper Weight Paper Capacity 1 Bin 2 Bin Staple Paper Size Paper Weight Capacity Point Punch Paper Size Paper Weight Electrical Requirements Dimensions (W × D × H) Weight Applicable Model Non-sort/Sort Non-sort/Shift-Sort (Letter Portrait only)/Staple (Letter Portrait only) Invoice/Letter/Letter-R/Legal/Ledger Letter 16 - 35 lb (60 - 135 g/m2): Non-sort mode 100 sheets Maximum: 1000 sheets / 30 set (Stapling mode) Letter 17 - 21 lb (64 - 80
Others Options and Supplies ■ The DP-3530/4530/6030 is a digital photocopier which can produce images with great clarity. Furthermore, its copying functionality can also be greatly enhanced by the addition of the following options and supplies. We hope you find that the wide ranging capabilities will make your office-place more productive and efficient. ■ Options Part Name Part No.
■ Supplies Part No.
Others INDEX 1 21 ..................................................................... 42 2 11 ..................................................................... 42 2 21 ..................................................................... 42 2PAGE ........................................................................ 44 2-Sided/Original Copy ................................. 15, 42-47 D Date Stamp ................................................................. 54 Delete printing job(s) ...........
M Q Making Copies With Opening the ADF ....................... 62 Margin ......................................................................... 52 Marked Copies ............................................................ 87 Maximum Prints .......................................................... 79 Misfed Location Indicator ............................................ 20 Misfed Paper (1-Bin Saddle-Stitch Finisher Only) ....... 28 Misfed Paper (2-Bin Finisher) .....................................
Others Z ZOOM ......................................................................... 50 Zoom/Effects ....................................................
IMPORTANT INFORMATION When requesting information, supplies or service always refer to the model and serial number of your machine. The model and serial number plate (Main Name Plate) is located on the rear side of machine. For your convenience, space is provided below to record information you may need in the future. Model No. Serial No.
USA Only WARRANTY PANASONIC DIGITAL DOCUMENT COMPANY MAKES NO WARRANTIES, GUARANTEES OR REPRESENTATIONS, EXPRESSED OR IMPLIED, TO CUSTOMER WITH RESPECT TO THIS PANASONIC MACHINE, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
