Specification Sheet

FLA Series
Newberry
Residential Leverset
10/2010
ADA
Push Button
4-3/4”
2-7/16”
2-13/16”
2-5/8”
** Entry Function Leverset **
CODE COMPLIANCE
Meets ADA Requirements
• Entry w/ ADA (FLA07C)
• Privacy w/ ADA (FLA08C)
WARRANTY
• Lifetime mechanical warranty
• Five years finish warranty
FUNCTIONS
Entry – F109 (FLA00)
Both lever locked or unlocked by key outside
or turn-piece inside.
Privacy – F76 (FLA01)
Both levers locked or unlocked by turn-piece
inside. Outside lever unlocked by coin or
screwdriver.
Bathroom-Split Finish – F76 (FLA09)
Same function as Privacy. Inside lever is
Polished Chrome.
Passage – F75 (FLA03)
Both levers always free.
Half Dummy (FLA04)
For doors where only pull is required.
Entry w/ ADA – F109 (FLA07C)
Outside lever locked or unlocked by key. Inside
lever locked by push-button and always free
with quick release function. No unlocking
required for panic exit.
Privacy w/ ADA – F76 (FLA08C)
Outside lever lock or unlocked by coin or
screwdriver. Inside lever locked by push-button
and always free with quick release function. No
unlocking required for panic exit.
FEATURES & OPTIONS
Door Preparation
Cross Bore: 2-1/8”, Edge: 1”
Latch Backset
Exterior: 2-3/8” deadlatch standard
Interior: 2-3/8” plainlatch standard
(other options available)
Faceplate
1” x 2-1/4” round corner standard
(other options available)
Bolt
1/2” throw
Door Thickness
Fit 1-3/8” to 1-3/4” standard
(extension kit available for 1-3/4” to 2-1/4” door)
Cylinder
5-pin KW keyway solid brass cylinder standard
5-pin SC “C” keyway available
Strike Plate
2-1/4” x 1-3/4” round corner full lip standard
(other options available)
Handing
Specify Right or Left door handed. Reversible
levers available
ANSI/BHMA
ANSI/BHMA A156.39 Grade 3
FINISHES
(other finishes available upon request with lead-time)
□ US3 – 605 – Polished Brass
□
US10B – 613 – Oil Rubbed Bronze
□ US15 – 619 – Satin Nickel
□ US15A – 620 – Antique Nickel
