Chapter 3: Technical Specifications
Communications
Operating frequenc
y
From 860, 930MHz and 2.4 GHz. Specific frequency used varies by region.
Wireless protocol
Proprietary frequency hopping, self-configuring, load-balancing mesh network
Wired network protocol
TCP/IP (one IP address needed per Gateway), support for Modbus TCP/IP and
SNMP protocols
Firmware updates
Wireless
Typical transmission
range
10 to 50 meters indoors from any one device to any other
Antenna
Fully enclosed, fixed configuration
Cable to Gateway ratio
Up to 300 cables per gateway (unlimited Gateways per system)
Multi-site support
Yes
Encryption
Optional 128-bit
Environmental
Operating temperature
-7° to +45°C (+20° to +113°F)
Operating humidit
y
5% to 95% non-condensing
Water and dust resistance
Indoor applications
Max. operating altitude
3,300 meters (10,000 feet)
Power usage
Smart power cable: 0.6W Ethernet Gateway: 0.7W
Outputs
LED status indicators
Power (Red / Orange), Status (Red/Orange), Communications (Green)
Local displa
y
3 Digit LED (cycles Amps, Volts, Watts by phase); user definable
Monitored points
Voltage (V), Current (A), Power (W), Energy (Wh), Apparent Power (VA), Power
Factor (PF), Frequency (Hz), Internal Temperature; all measurements +/- 1%,
Temperature (+/-2°C)
Outputs
LED status indicators
Power (Red / Orange), Status (Red/Orange), Communications (Green)
Local displa
y
3 Digit LED (cycles Amps, Volts, Watts by phase); user definable
Monitored points
Voltage (V), Current (A), Power (W), Energy (Wh), Apparent Power (VA), Power
Factor (PF), Frequency (Hz), Internal Temperature; all measurements +/- 1%,
Temperature (+/-2°C)
Size and Weight
S Models under 16
A
150 cm (60 in), 0.45kg (1 lbs)
S Models 16A and above
120 cm (48 in), 0.75 – 1.0kg (1.5 to 2 lbs)
R Models
Approximately 120 cm (48 in), 1.5 to 3 kg (3.5 to 7 lbs)
P Models
Varies – see product manual
Enclosure material
High-impact resistant Lexan, V0 flammability rating
Power cords
Each cord carries standard industry markings that describe its intended
operating environment and power type
