ULTRA ADVANTAGE SERVO ROLL FEED 2/09/2002

Example: If a feed pitch/length of 11.138 inches is entered into the feeder, this will result in exactly one revolution of

the feed rolls. The motor will accelerate and turn 10.24 turns. This will produce (10.24 x 8000 = 81,920) pulses of

the encoder. The feeder will decelerate and stop, when 81,920 pulses are detected. The feeder is now in position.

The result is an accurately positioned strip exactly 11.138 inches from its starting point. This entire process happens

in milliseconds.

2 PROGRAMMING THE ULTRA ADVANTAGE SERVO ROLL FEED

SYSTEM - OVERVIEW

NOTE: Before attempting any programming, make sure that the “PROGRAMMING LOCKED /

UNLOCKED” key switch is in the “Unlocked” position.

NOTE: After power shutdown, WAIT for 10 seconds before powering up the Feed.

Turn on the main power disconnect switch. This applies power to the control power supply. Press the green Power

On push-button. The button will illuminate and the OPERATOR terminal display will be visible.

Wait for the IN POSITION light to illuminate.

Press any key to begin.

P / A I n d u s t r i e s

R e a l l y C o o l F e e d

V e r s i o n 1 . 1 6 S F I

H i t a n y k e y t o c o n t .

NOTE: The OPERATOR terminal has three mode keys, they are:

● “OPER”

● “TOOLS” ” – disabled on SFI model.

● “SETUP

NOTE: ▓ The flashing cursor is waiting for the value to be entered.

NOTE: < The pointer prompts to press the “ENTER” key.

NOTE: To confirm any value, press “ENTER”.
