Fiberglass-Based Asphalt Shingles & Accessories

2. Patented corrugated ridge design and interlocking feature for additional flexibility and strength

3. Provides 20 sq in (12900 sq mm) NFVA per lineal foot.

4. Optional Weather PROtector

filter provides added protection against wind-driven rain and

snow infiltration.

5. 15 in (381 mm) wide and 1 in (25 mm) high, with a shingle-over width of 12 in (305 mm).

6. Suitable on roofs with a pitch from 3:12 to 6:12.

7. Standards/Qualifications: Passes Wind-Driven Rain with 8.8 in (224 mm) of rain/hr at 110 mph

(177 km/h), UL ER21292-01, Florida Product Approval, Miami-Dade County Product Approval,

and TDI listed for usage in Texas Coastal Regions (RV-47).

D. VentSure

4 ft (1.2 m) Strip Heat and Moisture Ridge Vent, 8 in (203 mm) and 10 in (254 mm) width.

1. Shingle-over, polypropylene ridge ventilator designed to work with eave/soffit intake ventilation

to maximize the flow of cool, fresh air through the roof and attic structure.

2. Patented corrugated ridge design and interlocking feature for additional flexibility and strength.

3. Provides 18 sq in (11600 sq mm) NFVA per lineal foot.

4. Optional Weather PROtector

filter provides added protection against wind-driven rain and

snow infiltration.

5. Available in 8 in (203 mm) and 10 in (254 mm) shingle-over widths that are 1 in (25 mm) high

and overall product width is 11.43 in (290 mm) and 13.28 in (337 mm), respectively.

6. Suitable on roofs with a pitch from 3:12 to 16:12.

7. Standards/Qualifications: Passes Wind-Driven Rain with 8.8 in (224 mm) of rain/hr at 110 mph

(177 km/h), UL ER21292-01, Florida Product Approval, Miami-Dade County Product Approval,

and TDI listed for usage in Texas Coastal Regions (RV-47).

E. VentSure

SkyRunner LTE™ Rolled Ridge Vent

1. Shingle-over, polypropylene ridge ventilator designed to work with eave/soffit intake ventilation

to maximize the flow of cool, fresh air through the roof and attic structure.

2. Provides 12 sq in (7742 sq mm) NFVA per lineal foot.

3. Available in 30 ft (9.1 m) rolls in 14-

in (368 mm) width.

4. Suitable on roofs with a pitch from 2:12 to 16:12.

5. Standards/Qualifications: Passes Wind-Driven Rain with 8.8 in (224 mm) of rain/hr at 110 mph

(177 km/h), ICC-ES AC132, UL ER21292-01, Florida Product Approval.

F. VentSure

Metal Slant Back Roof Vent

1. Rooftop mounted, slant-back designed, metal exhaust ventilator designed to evacuate hot

and/or moisture-laden air from attics.

2. Each vent provides 51 sq in (32900 sq mm) NFVA.

3. Aluminum and galvanized steel available in Weathered Grey, Brown, Black, or Mill Finish.

4. 16 in (406 mm) by 20 in (508 mm) base, 8 in (203 mm) diameter opening.

5. Suitable on roofs with a pitch up to 12:12.

6. Standards/Qualifications: TDI listed for usage in Texas Coastal Region (RV-20)

G. Plastic Slant Back Roof Vent

1. Rooftop mounted, slant-back design with full screen, high-impact resin exhaust ventilator

designed to evacuate hot and/or moisture-laden air from attics.

2. Each vent provides 55 sq in (35500 sq mm) NFVA.

3. Available in Weathered Grey, Brown, Black, Cedar, or White finish.

4. 17 in (432 mm) by 18 in (457 mm) base, 9 in (229 mm) by 9 in (229 mm) opening.

5. Standards/Qualifications: TDI listed for usage in Texas Coastal Regions (RV-20).

H. VentSure

Metal Square Top Roof Vent

1. Rooftop mounted, square-top designed, metal exhaust ventilator designed to evacuate hot

and/or moisture-laden air from attics.

2. Each vent provides 51 sq in (32900 sq m) NFVA.

3. Aluminum and galvanized steel available in Weathered Grey, Brown, Black, or Mill finish.
