GSLC175-230 – Components
Figure 4 GSLC175-230 Components
Inverter (negative) DC Bus Bars
Negative Terminal Bus Bar (TBB)
Ground TBB
Neutral TBB
PV TBB
DC Positive Cable Plate
Main Inverter Disconnect(s)
Inverter (positive) DC Bus Bars
Shunt
AC Circuit Breakers
Maintenance Bypass Interlock
AC TBB (Inverter Output)
AC TBB (Grid)
AC TBB (Generator)
Le
g
end
12
11
1
2
3
4
5
6
7
8
9
10
14
13
1
211
10
9
7
3
8
6
5
12
13
14
5 4
NOTE: The factory wiring has been omitted from this illustration for clarity.
