GSLC – Components
Figure 2 GSLC Components
Inverter (negative) DC Bus Bars
Negative Terminal Bus Bar (TBB)
Ground TBB
Neutral TBB
PV (Positive) TBBs
Shunt
NOTE: The installed Neutral TBB has white insulators.
A set of blue insulators is included in the kit for
locations where blue is standard.
Inverter positive DC bus bars and DC positive bus
plate are also included in the kit.
