Installation Manual Instruction Manual

Installation
28 900-0123-01-00 Rev B
Figure 28 PV Connections in the GSLC
Figure 29 PV Connections in the FLEXmax Charge Controller
BAT– BAT+
PV Negative (–)
Battery Negative (–)
PV Positive (+)
Battery Positive (+)
PV+ PV–
PV Positive (+) TBB
DC Positive (+) plate
Shunt
GFDI
PV Disconnect
Negative TBB
