46
Image Frequency Attenuation (@ 25°C) 45 dB
Local Oscillator Leakage 2 nW
Adjacent Channel Attenuation 30 dB
RSSI Range -120 -47 dBm
Operating Current (incl. onboard microcontroller)
c
35 mA
Transmitter (all measurements made on a 50 Ohm resistive load)
Output Power -20 +12 dBm
Spurious Radiation (0 to 862 MHz) 2 nW
Spurious Radiation (862 MHz to 3.5 GHz) 200 nW
Adjacent Channel Power (12.5 kHz version) -50 dBm
Adjacent Channel Power (25 kHz version) -50 dBm
Occupied Bandwidth (12.5 kHz version) 8.5 kHz
Occupied Bandwidth (25 kHz version) 15 kHz
Operating Current (incl. onboard microcontroller) 40 mA
Datalogger
Analog Inputs 0 2.5 V
Analog Input, Low Voltage Amplifier enabled 0 100 mV
Digital Inputs V
il
0.5 V
Digital Inputs V
ih
2.4 V
Pulse Counter Input Frequency
d
10 Hz
Digital Outputs Sink/Source 1 mA
Digital Outputs V
ol
0.3 V
Digital Outputs V
oh
2.4 V
a. Data rate is content dependent.
b. This parameter represents the tuning range; the switching range may be limited in
the software to a narrower space (even to the extent of a single channel).
c. Continuous duty.
d. Electrical levels are the same as for the Digital Inputs.
Table 5. Operational Parameters (Continued)
Parameter Min Typ Max Unit
