CHAPTER 3
Using terminal commands
29
The remote version is limited to a single frame. An example of
such a command is given below:
6367 DATA 6367 30/4/1999 14:50:00
6367 DATA
30 4 1999 14 54 55 14 38 255 255 77 0 0 89 156 126
20 0 0 0 0
3185 0
#
Notice that if you need to get data that is not the last (newest) slot
remotely from a device, the ID must be supplied twice. If you need
to get the last slot stored, you can ignore the ID and the date/time
parameters:
8300 DATA
8300 DATA
13 5 1999 19 26 36 14 38 255 255 79 0 0 87 148 149
15 0 0 0 0
3138 0
COMMAND FDEV
DESCRIPTION Displays info about internal memory or formats the internal mem-
ory (destroys all the data)
PARAMETERS None (to query the current format) or the new EEPROM type and
optional the number of index entries. To format the EEPROM with
the currently set type, specify type 0.
In GET mode, the following information is printed:
current EEPROM type, the sizes of the two EEPROM chips, the
range for index size, the total/used index entries, the total/used
number of bytes for measurement data.
Table 3. EEPROM Types
Type Memory [kB] Min index entries Default index entries May index entries
1 16 64 256 1024
2 16+16 128 512 2048
3 32 128 512 2048
4 16+32 192 768 3072
