Owner manual

1. Description 5
1.1. DALI
®
– digital addressable lighting interface 6
1.2. StepDIM – midnight step-down/half-night switch 6
1.3. AstroDIM – autonomous dimming without external control 7
2. 3DIM interface (ECG terminals) 8
3. Mode selection 8
3.1. Via wiring selection (factory settings) 8
3.2. Via 3DIM Tool software 8
4. Wiring and confi guration of the ECG 9
4.1. DALI
®
– digital addressable lighting interface 9
4.1.1. Wiring 9
4.1.2. Control line – cable requirements 10
4.1.3. Connection via power-line converter 11
4.2. StepDIM – midnight step-down/half-night switch 12
4.2.1. Wiring 12
4.2.2. Parameter setting via 3DIM Tool 14
4.3. AstroDIM – autonomous dimming without external control 16
4.3.1. Wiring 16
4.3.2. Parameter setting via 3DIM Tool 18
5. Frequently asked questions (FAQ) 20
5.1. General questions 20
5.2. Questions regarding DALI
®
20
5.3. Questions regarding StepDIM 20
5.4. Questions regarding AstroDIM 21
6. List of abbreviations and defi nitions 23
4
Content
CONTENT
