Datasheet

Technical Information
No. FO 4265
High-Voltage Halogen Lamp
Edition: 02/05
- subject to change
supersedes: 05/02
Status: valid
64516
230V / 240V
DISPLAY/OPTIC Berlin
 Product description
Halogen lamp for photo- and video- luminaries and
for studio. The 64516 is the long-life lamp of the 64515
with 75h average service life.
 Technical data
Order reference 64515
ANSI -
LIF CP/97
Voltage V 230
1
Rated wattage W 300
Luminous flux lm 7900
2
Colour temperature K 3100
Lamp len
g
th l
mm max. 53
LCL a
mm 27±1
Bulb diameter d
mm max. 18.5
Filament dimensions (w x h) mm 9.72 x 12.5
Type of filament Dimple technology
Average service life h 75
Base GX 6.35
 Required conditions of operation
Burning position s90
Maximum permissible seal
temperature
°C 450
Required protection G-melt flow field 250V, quick, 4 A, DIN 41660 (CEE 4/IEC 127)
1
also available in 240V
2
240V: 7800 lm
