To read the internal MPU-60X0 registers, the master sends a start condition, followed by the I
2
C address and
a write bit, and then the register address that is going to be read. Upon receiving the ACK signal from the
MPU-60X0, the master transmits a start signal followed by the slave address and read bit. As a result, the
MPU-60X0 sends an ACK signal and the data. The communication ends with a not acknowledge (NACK)
signal and a stop bit from master. The NACK condition is defined such that the SDA line remains high at the
9
th
clock cycle. The following figures show single and two-byte read sequences.
Single-Byte Read Sequence
Burst Read Sequence
9.4 I
2
C Terms
Signal
Description
S
Start Condition: SDA goes from high to low while SCL is high
AD
Slave I
2
C address
W
Write bit (0)
R
Read bit (1)
ACK
Acknowledge: SDA line is low while the SCL line is high at the
9
th
clock cycle
NACK
Not-Acknowledge: SDA line stays high at the 9
th
clock cycle
RA
MPU-60X0 internal register address
DATA
Transmit or received data
P
Stop condition: SDA going from low to high while SCL is high
Master
S
AD+W
RA
S
AD+R
NACK
P
Slave
ACK
ACK
ACK
DATA
Master
S
AD+W
RA
S
AD+R
ACK
NACK
P
Slave
ACK
ACK
ACK
DATA
DATA
