Back Panel
Item Description
1.LAN Port • LAN port for connecting to an Ethernet network through a switch
or router
2.WAN Port • WAN port for connecting to an Ethernet network through a switch
or router
3.Serial Port • This port is for external UPS device
4.eSATA Port • eSATA port for high-speed storage expansion
5.USB Port • USB 2.0 port for compatible USB devices, such as USB disks, and
USB printers
6.System Fan • System fan that exhausts heat from the unit
7.Power Connector • Connect the included power cords to these connectors
