Chapter 10: Version 3.01.00 Firmware Updates

What’s New

There are additional features implemented into the new 3.01.00 version firmware.

Updated Login User Interface

The design of the admin login UI has been completely updated.

NOTE

The previous chapters have screenshots of the original user interface.

Please note that all changes are visual only. There are no functional

changes.

Updated Main User Interface

The look and icons of the main user interface have been updated. Additionally, a “My

Favorite” shortcut has been added to allow the user to designate often used items

and have them display on the main screen area. The figure below displays 12 default

favorite functions.

134
