Hard Disk Trays

Each of the N7700SAS’s hard disk trays has

a lock, a latch, and two LED indicators:

3 4 5

Hard Disk Trays

Item Description

1.HDD Power LED • Solid blue: hard disk is powered on

2.HDD

Access/Error LED

• Blinking green: system is accessing data on the hard disk

3.Lock • Use the lock to physically secure the hard disk to the unit

4.Latch • Use to open and remove or close and secure the tray

5.Handle • Pull out HDD tray

Rear Panel

The N7700SAS rear panel features ports and connectors.
