Chapter 9: Revision updated up to FW 3.00.08

What’s New

There are additional features implemented into the new 3.00.08 version firmware.

Updated Login User Interface

There is a brand new design for the admin login UI.

NOTE

The previous chapters have screenshots of the original user interface.

Please note that all changes are visual only. There are no functional

changes.

Updated Photo Server User Interface

Same as the admin login user interface, the photo server has a brand new art design

from its previous version.

128
