en.indd 1 User Manual Item No.
en.indd 2 Oregon Scientific, Inc. 19861 SW 95th Avenue Tualatin, OR 97062, USA Hotline: 1-800-853-8883 Service: http://us.oregonscientific.com/service Website: http://us.oregonscientific.com Oregon Scientific (UK) Limited Unit 1, Switchback, Gardner Road Maidenhead, Berkshire SL6 7RJ, UK Tel: 44 1 628 580 154 Fax: 44 1 628 634 981 Website: www.oregonscientific.co.uk Email: technical@oregonuk.
en.
en.indd 2 Precautions - Camera Notice the following guidelines when using your camera • The camera is shock resistant, not shock proof. • Do not let operating the camera distract you from your immediate surrounding. • Do not place the camera in areas prone to dust or damp for long periods of time. This may cause a fire or an electric shock. • Do not leave the camera in places exposed to extremely high temperatures, such as under direct sunlight, for long periods of time.
en.indd 3 EN Precautions - Battery If the rechargeable battery is mishandled, it can burst, cause a fire or even chemical burns. Observe the following cautions: • Never charge the battery around or in area of any inflammable materials. • Do not incinerate or dispose of the battery in fire. • Do not short circuit and do not allow metal objects to come into contact with the battery terminals. • Do not expose the battery to extreme temperatures below 0°C (32°F) or above 40°C (104°F).
en.indd 4 Precautions - Waterproof • • • • The camera is waterproof up to 20m (60ft). Oregon Scientific will not assume any responsibility for camera malfunction caused by liquid entering the camera as a result of misuse by the user. Liquid may get inside the camera if the battery cover is not firmly closed. If the camera gets wet, wipe the liquid off as soon as possible with a dry cloth. Other camera accessories may not be waterproof.
en.
en.indd 6 Operating Elements - Battery Installation & Charging • • Insert the provided battery to the battery compartment. The metal contacts should face toward the camera. Lever the latch to pull the battery out. Make sure the battery is locked in place. 1. Connect the camera to a USB port through USB cable. The status indicator will flash green and red alternately and two beeps will be generated. 2. When charging is finished, the status indicator turns green and a long beep will be generated.
en.indd 7 EN Operating Elements - Date & Time Setting 1. Create SETTINGS.txt file with Notepad (Windows) or TextEdit (Mac). 2. Type in the predicted time when you insert the MicroSD card in the following format* YYYY.MM.DD hh:mm:ss xxHz Please note that both filename and the content are case sensitive. 3. Save the .txt file in the root folder of the MicroSD card. 4. Insert the MicroSD card and turn on the ATCMini, the camera will be updated the date and time.
en.indd 8 Operating Elements - MicroSD Card Insertion & Formatting MicroSD card insertion 1. Insert the MicroSD card until it clicks into place, the metal contacts should be facing upward. 2. To remove the MicroSD card, push it further into the camera and it will spring out from the camera for being pulled out. Insert or remove the MicroSD card only when the camera is turned off. MicroSD card formatting 1. Press and hold to turn on the camera. 2. Press and hold , and to format the MicroSD card. 3.
en.indd 9 EN Operation - Main Buttons Video recording to start. Press RED Press the button again to stop. Camera beeps once and status indicator turns red. Photo shooting Single mode: Press to take one photo. Continuous mode: Press and hold to take 9 photos consecutively. FLASHES RED Camera beeps and status indicator flashes red whenever a photo is taken. Power on / Off Press and hold to turn on / off the camera.
en.indd 10 Operation - Connecting to Monitor 4 3 1 1. 2. 3. 4. 2 Open the rear part of camera. Insert the 2.5 mm stereo plug to the camera video output. Connect the RCA plugs to the monitor, yellow plug to video input and white plug to audio input. Turn on the camera.
en.indd 11 EN Operation - On-Screen Menu S Single photo Contiunous photos S M Video S S • • • M After the start up screen, the home page will appear will the four icons, , , and . Use or to navigate and to confirm / select. The toolbar hides automatically when no button is pressed for 2 seconds. Press any buttons to show the toolbar again.
en.indd 12 Operation - On-Screen Menu index & Connecting to Computer On-Screen Menu Index On-screen Function icon Video S M On-screen Function icon Slide show On-screen Function icon Fast forward Single photo Confirm Rewind Continuous photos Cancel Delete Delete all files Play Return Previous Pause Return to homepage Next Stop Delete selected file Connecting to a computer with Windows operating system 1. Connect the camera to a computer with the provided USB cable. 2.
en.
en.indd 14 Mounting - Basic & Tripod Mount Basic mounting 1. Insert the camera to the quick release bracket. 2. Tighten the screw to secure the camera. 3. The quick release bracket can be attached to different mounts. 1 2 Tripod Mounting Slide the quick release bracket to the tripod mount.
en.indd 15 EN Mounting - Other Mounting Options The camera can be mounted on hardshell helmet, surfboard or handlebar of bicycle or motorcycle with designated mounts. Other cameras from the ATC series can also utilise those mounts through conversion set. The camera grip of the ATC conversion set can be used for ATC3K & ATC9K. ATC5K users can make use of the existing ATC5K grip along with the ATC conversion set’s quick release to work with our new mounting series.
en.indd 16 Specification Power consumption: DC3.7V; 0.92W Battery 3.7V LiPo; 445mAh / 1.65Wh Photograph resolution 1.3 MP Field of view 110º Video format AVI Video quality* 720p (1280 x 720 pixels); 16:9; 30fps; ~8Mbit / s data rate, approximately 15 minutes of video per 1 Gbyte Audio format Mono USB interface USB 2.0 Operating systems Windows XP / Vista / Windows 7 or Apple Mac OS X 10.
mately bove en.indd 17 EN FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING ’s authority to operate the equipment.
en.indd 18 Disclaimer DEFINITION: “Oregon Scientific” shall mean Oregon Scientific Global Distribution Limited, its subsidiaries, parent companies, affiliated companies, directors, officers, employees, agents, representatives and distributors. DISCLAIMER: Oregon Scientific do not warrant against loss of any data (including data stored on Product), and assume no liability for such loss.
en.indd 19 EN Disclaimer The foregoing limitations will apply even if any warranty or remedy provided herein fails of its essential purpose. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to Purchaser.
