beeps(0.1s) indicating that the system is ready
 When module transmits RF packet red LED is ON. Therefore it is ON during
binding and standard transmitting procedures
 The module works in so called “non-fixed ID” mode. Every time the power is
recycled a binding procedure will be automatically initiated.
 After power ON and receiving valid PPM signal the module enters BIND mode
and transmits bind packets for 10 seconds. During this time receiver should be
turned on to initiate binding procedure. After 10 seconds binding procedure is
over and the module enters the regular transmitting mode and stays in this
mode until power turned off.
 After recycle power the sequence of procedures repeats
ID change:
 When powered up with Button1 pressed the new ID will be generated. The
procedure of new ID generation is initiated regardless if PPM signal present or
not. After detection of Button 1 pressed module waits for 3 sec then generated
a new ID and buzzer generates long beep(0.3 sec). After this the module waits
until the button 1 is released. When button is released the module detects PPM
signal from the radio. In Wakera mode as soon as PPM signal is detected the
module enters binding mode and following standard transmission mode. In
Spektrum mode following binding procedure is necessary.
2. Spektrum mode Auto SW1-OFF, SW3-OFF
Inputs and outputs:
 SW2 provides channel mapping according to switch description
 SW4 SW5, SW6 are ignored
 SW7, SW8 change output power selection according to switches description
 Button1 – ID change
 Button2 – When pressed during operation the output power is reduced to
xxmW for a range check. When pressed during power on a binding procedure
will be initiated
 Buzzer – see Functionality
 LED – see Functionality
Functionality
Power ON:
 When powered up the module is waiting for valid PPM signal to be detected.
 As soon as PPM signal is detected the buzzer generates three short
beeps(0.1s) indicating that the system is ready
 When module transmits RF packets red LED blinks in accordance to the mode
selected during binding.
DSM2, 1024 mode – OFF
DSM2, 2048 mode – single blinks
DSMx, 22ms mode – double blinks
DSMx, 11ms mode – triple blinks
