4. SW4: DSM2/DSMx. Selects DSM2/DSMx protocols in manual mode
OFF-DSM2
ON-DSMx
Switch position will be ignored in auto mode(when SW3 is ON)
5. SW5: 11ms/22ms for DSM2 and DSMx
ON-11ms
OFF-22ms
Switch position will be ignored in auto mode(when SW3 is ON)
6. SW6: 1024/2048 for DSM2 only.
OFF-1024
ON-2048
Switch position will be ignored in auto mode(when SW3 is ON) and for DSMx
7. SW7, SW8: Output power selection
SW7-ON, SW8-ON - 10mW
SW7-ON, SW8-OFF - 25mW
SW7-OFF, SW8-ON - 50mW
SW7-OFF, SW8-OFF - 100mW
During binding procedure the output power is fixed at 25mW regardless of the
switch positions
During Range test procedure the output power is fixed at xxmW
regardless of the switch positions.
LED, Buzzer, Connector and Buttons description
LED color and functionality
 Color – red
 Functionality:
multiple functionality depending on mode used
DSM2, 1024 mode – OFF
DSM2, 2048 mode – single blinks
DSMx, 22ms mode – double blinks
DSMx, 11ms mode – triple blinks
Walkera Devo – continuously ON
Buzzer
 Frequency – 2.67kHz
 Functionality:
When powered on in presence of PPM signal
- three short beeps
During binding procedure:
- successful binding - three short beeps
- unsuccessful binding – single long beep
- During range test – continuous short beeps once every second.
Connectors
