User Manual

Project Overview Statement—Executive Summary

Confidential Page 2 4/8/2015

Primary Project Objectives

Design the module having the same basic functionality as Assan and Orange modules

and in addition to extend to an advanced functionality selected by 8 single pole dual

throw switches.

 Adding new protocols – Walkera, DSMx – 22ms/11ms

 Automatic selection of the most advanced protocol available

 Manual selection of the protocol and settings in case if automatic selection is not

preferable

Primary Project Deliverables

Milestone 1

 Design DSM2 –1024/22ms, 2048/11ms protocols - preliminary

 Design DSMx – 22ms/11ms protocols - preliminary

 Design Walkera Devo protocol - preliminary

Milestone 2

 Design binding procedure for DSM2 with integration with DSM2 protocol

 Design binding procedure for DSMx with integration with DSMx protocol

 Design binding procedure for Walkera Devo with integration with Walkera protocol

Milestone 3

 Design channels mapping AETR/TAER compatible with JК and Futaba respectfully

 Design LED and Buzzer functionality in accordance to the description provided

 Design buttons functionality in accordance to the description provided

 Design switches functionality according to description

 Design output power control according to description

Switches

Switches functionality description

1. SW1: Walkera/DSM2(x) protocol selection.

ON-Walkera,

OFF-DSM2(x)

In Walkera mode SW3..SW6 are ignored.

2. SW2: Channel mapping.

ON-AETR

OFF-TAER

3. SW3: DSM2(x) Auto/Manual settings for DSM2(x).

OFF-Auto mode

ON-Manual mode
