Operation Manual

55
English
Appendices
SEND to projector
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code HEX Code Function Description
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX73 n<CR> 7E 30 30 37 33 20 n 13 Signal Fre
quency n= -100 - 100
~XX74 n<CR> 7E 30 30 37 34 20 n 13 Phase
n= 0 - 63
~XX75 n<CR> 7E 30 30 37 35 20 n 13 H
. Position n= -100 - 100
~XX76 n<CR> 7E 30 30 37 36 20 n 13 V
. Position n= -100 - 100
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX77 n<CR> 7E 30 30 37 37 20 nnnnnn 13 Security S
ecurity Timer Month/Day/Hour nnnnnn
~XX78 1<CR> 7E 30 30 37 38 20 31 13 S
ecurity Settings Enable
~XX78 2<CR> 7E 30 30 37 38 20 32 13 D
isable
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX79 n<CR> 7E 30 30 37 39 20 n 13 Projector ID
n= 01 - 99
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX80 1<CR> 7E 30 30 38 30 20 31 13 Mute O
n On
~XX80 2<CR> 7E 30 30 38 30 20 32 13 O
ff Off
~XX81 n<CR> 7E 30 30 38 31 20 n 13 Volume
n= 0 - 10
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX82 1<CR> 7E 30 30 38 32 20 31 13 Logo O
ptoma
~XX82 2<CR> 7E 30 30 38 32 20 32 13 U
ser
~XX83 1<CR> 7E 30 30 38 33 20 31 13 Logo Capture
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX86 1<CR> 7E 30 30 38 36 20 31 13 RS232 Port RS2
32
~XX86 2<CR> 7E 30 30 38 36 20 32 13 N
etwork
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX100 1<CR> 7E 30 30 31 30 30 20 31 13 Source Lock
On
~XX100 2<CR> 7E 30 30 31 30 30 20 32 13 O
ff
~XX101 1<CR> 7E 30 30 31 30 31 20 31 13 High Altitude
On
~XX101 2<CR> 7E 30 30 31 30 31 20 32 13 O
ff
~XX102 1<CR> 7E 30 30 31 30 32 20 31 13 Information Hide
On
~XX102 2<CR> 7E 30 30 31 30 32 20 32 13 O
ff
~XX103 1<CR> 7E 30 30 31 30 33 20 31 13 Keypad Lock
On
~XX103 2<CR> 7E 30 30 31 30 33 20 32 13 O
ff
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX104 1<CR> 7E 30 30 31 30 34 20 31 13 Background Color Blue
~XX104 2<CR> 7E 30 30 31 30 34 20 32 13 Black
~XX104 3<CR> 7E 30 30 31 30 34 20 33 13 Red
~XX104 4<CR> 7E 30 30 31 30 34 20 34 13 Green
~XX104 5<CR> 7E 30 30 31 30 34 20 35 13 White
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX105 1<CR> 7E 30 30 31 30 35 20 31 13 Advanced Direct Power On On
~XX105 2<CR> 7E 30 30 31 30 35 20 32 13
Off
~XX113 1<CR> 7E 30 30 31 31 33 20 31 13 S
ignal Power On On
~XX113 2<CR> 7E 30 30 31 31 33 20 32 13
Off
~XX106 n<CR> 7E 30 30 31 30 36 20 n 13 Auto Power Off (min) n= 0 - 999
~XX107 n<CR> 7E 30 30 31 30 37 20 n 13 Sleep Timer (min) n= 0 - 999
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX108 1<CR> 7E 30 30 31 30 38 20 31 13 Lamp Setting L
amp Hours
~XX109 1<CR> 7E 30 30 31 30 39 20 31 13 L
amp Reminder On
~XX109 2<CR> 7E 30 30 31 30 39 20 32 13
Off
~XX110 1<CR> 7E 30 30 31 31 30 20 31 13 B
rightness Mode Bright
~XX110 2<CR> 7E 30 30 31 31 30 20 32 13
STD
~XX111 1<CR> 7E 30 30 31 31 31 20 31 13 L
amp Reset Yes
~XX111 2<CR> 7E 30 30 31 31 31 20 32 13 N
o
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX112 1<CR> 7E 30 30 31 31 32 20 31 13 Reset
Yes
~XX112 2<CR> 7E 30 30 31 31 32 20 32 13 N
o
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND to Remote
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX140 1<CR> 7E 30 30 31 34 30 20 31 13 Power
~XX140 2<CR> 7E 30 30 31 34 30 20 32 13 Re-sync
~XX140 3<CR> 7E 30 30 31 34 30 20 33 13 Keyston
~XX140 4<CR> 7E 30 30 31 34 30 20 34 13 AV Mute
~XX140 5<CR> 7E 30 30 31 34 30 20 35 13 Freeze
~XX140 6<CR> 7E 30 30 31 34 30 20 36 13 Pisplay
~XX140 7<CR> 7E 30 30 31 34 30 20 37 13 Zoom in
~XX140 8<CR> 7E 30 30 31 34 30 20 38 13 Zoom out
~XX140 9<CR> 7E 30 30 31 34 30 20 39 13 Volume +
~XX140 10<CR> 7E 30 30 31 34 30 20 31 30 13 Volume -
~XX140 11<CR> 7E 30 30 31 34 30 20 31 31 13 Enter
~XX140 12<CR> 7E 30 30 31 34 30 20 31 32 13 Menu
~XX140 13<CR> 7E 30 30 31 34 30 20 31 33 13 Left
~XX140 14<CR> 7E 30 30 31 34 30 20 31 34 13 Up
~XX140 15<CR> 7E 30 30 31 34 30 20 31 35 13 Right
~XX140 16<CR> 7E 30 30 31 34 30 20 31 36 13 Down
~XX140 17<CR> 7E 30 30 31 34 30 20 31 37 13 Clear
~XX140 18<CR> 7E 30 30 31 34 30 20 31 38 13 Format (1)
~XX140 19<CR> 7E 30 30 31 34 30 20 31 39 13 HDMI (2)
~XX140 20<CR> 7E 30 30 31 34 30 20 32 30 13 Source Lock (3)
~XX140 21<CR> 7E 30 30 31 34 30 20 32 31 13 Info. (4)
~XX140 22<CR> 7E 30 30 31 34 30 20 32 32 13 DVI (5)
~XX140 23<CR> 7E 30 30 31 34 30 20 32 33 13 Video (6)
~XX140 24<CR> 7E 30 30 31 34 30 20 32 34 13 VGA 1 (7)
~XX140 25<CR> 7E 30 30 31 34 30 20 32 35 13 Wireless (8)
~XX140 26<CR> 7E 30 30 31 34 30 20 32 36 13 S-Video (9)
~XX140 27<CR> 7E 30 30 31 34 30 20 32 37 13 VGA 2 (0)
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND from projector automatically
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code HEX Code Function Projector Return Description
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
when standby/warming/cooling/out of range/Lamp fail I
NFOn n : 0/1/2/3/4 = Standby/Warming/Cooling/Out of Range/
Lamp fail
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
READ from projector
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code HEX Code Function Projector Return Description
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX121 1<CR> 7E 30 30 31 32 31 20 31 13 Input Source Commands OKn n
: 0//1/2/3/4/5/6/7 = None/DVI/VGA1/VGA2/S-Video
V
ideo/HDMI/Wireless
~XX122 1<CR> 7E 30 30 31 32 32 20 31 13 Sofware Version OKdd
~XX123 1<CR> 7E 30 30 31 32 33 20 31 13 Display Mode O
Kn n : 0//1/2/3/4/5 = Presentation/Bright/Movie/sRGB/
U
ser1/User2
~XX124 1<CR> 7E 30 30 31 32 34 20 31 13 Power State OK
n n : 1/0 = On/Off
~XX125 1<CR> 7E 30 30 31 32 35 20 31 13 Brightness OK
n
~XX126 1<CR> 7E 30 30 31 32 36 20 31 13 Contrast OK
n
~XX127 1<CR> 7E 30 30 31 32 37 20 31 13 Aspect Ratio O
Kn n : 0//1/2/3 = 4:3/16:9-l/16:9-ll/Window
~XX128 1<CR> 7E 30 30 31 32 38 20 31 13 Color Temperature OKn n
: 0//1/2 = Warm/Medium/Cold
~XX129 1<CR> 7E 30 30 31 32 39 20 31 13 Projection Mode OKn n
: 0//1/2/3 = Front-Desktop/ Rear-Desktop/ Front-Ceiling/
R
ear-Ceiling
~XX150 1<CR> 7E 30 30 31 35 30 20 31 13 Information O
Kabbbbccdddde a : 1/0=On/Off
bbbb : LampHour
cc : source 00/01/02/030/04/05/06/07 = None/DVI/VGA1/
VGA2/S-Video/Video/HDMI/Wireless
dddd : FW version
e : Display mode = Presentation/Bright/Movie/sRGB/
U
ser1/User2
~XX151 1<CR> 7E 30 30 31 35 31 20 31 13 Model name OK
n n : 0/1 = EP776/EP782
