Table of Contents Table of Contents.............................1 Usage Notice....................................2 Safety Information................................2 Precautions..........................................3 Eye Safety Warnings...........................5 Product Features.................................5 Introduction.......................................6 Package Overview...............................6 Product Overview................................7 Main Unit...........................
Usage Notice Safety Information The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
Usage Notice Precautions Please follow all warnings, precautions and maintenance as recommended in this user’s guide. ▀■ Warning- Do not look into the projector’s lens when the lamp is on. The bright light may hurt and damage your eyes. ▀■ Warning- To reduce the risk of fire or electric shock, do not expose this projector to rain or moisture. ▀■ Warning- Please do not open or disassemble the projector as this may cause electric shock.
Usage Notice Do: Turn off and unplug the power plug from the AC outlet before cleaning the product. Use a soft dry cloth with mild detergent to clean the display housing. Disconnect the power plug from AC outlet if the product is not being used for a long period of time. Do not: Block the slots and openings on the unit provided for ventilation. Use abrasive cleaners, waxes or solvents to clean the unit. Use under the following conditions: - In extremely hot, cold or humid environments.
Usage Notice Eye Safety Warnings ▀■ Avoid staring/facing directly into the projector beam at all times. Keep your back to the beam as much as possible. ▀■ When projector is used in a classroom, adequately supervise students when they are asked to point out something on the screen. ▀■ In order to minimize the lamp power, use room blinds to reduce ambient light levels.
Introduction Package Overview Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact your nearest customer service center. Projector with lens cap Due to different applications in each country, some regions may have different accessories.
Introduction Product Overview Main Unit 6 1 2 4 3 6 5 4 7 8 4 4 9 4 10 11 Air Flow 1. 2. 3. 4. 5. 6. Control Panel Focus Ring Speaker Tilt-Adjustment Feet Lens IR Receiver 7. Input / Output Connections 8. Power Socket 9. Security Bar 10. Ventilation (inlet) 11.
Introduction Control Panel 2 3 4 11 SO UR CE 1 LAMP TEMP MENU POWER/STANDBY 10 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11.
Introduction Input/Output Connections 1 2 3 PB/MOUSE HDMI 4 VGA-OUT 5 VGA1-IN / YPbPr 6 7 S-VIDEO VIDEO 8 RS-232 9 10 AUDIO1-IN (VGA1/VGA2) SERVICE RJ-45 VGA2-IN / YPbPr MIC 12V OUT AUDIO 2-IN (S-VIDEO/VIDEO) DISPLAY USB / L R AUDIO OUT 12V OUT 19 Monitor loop through only support in VGA1-In/ YPbPr. 18 17 16 15 14 13 12 11 1. 2. 3. 4. 5.
Introduction Remote Control 1 2 The interface is subject to model’s specifications. 12 3 13 4 14 5 15 6 16 7 17 8 18 9 19 10 20 11 21 English 10 22 23 1. LED Indicator 2. Power On/Off 3. Four Directional Select Keys 4. Mouse Right Click 5. Page Up 6. Re-Sync 7. Page Down 8. Volume +/9. 3D 10. AV mute 11. Video 12. PC/Mouse control 13. Mouse Left Click 14. Enter/Help 15. Source 16. Keystone +/17. Menu 18. Brightness 19. HDMI 20. S-Video 21.
Introduction Interactive Pen 1 3 2 4 7 5 8 6 The interactive pen is optional accessory. 1. 2. 3. 4. Battery Cover Mouse Right Click Menu Mouse Left Click 5. 6. 7. 8. Lens Nib Power On/Off LED Indicators 1 Warning: • Danger of explosion if battery is incorrectly replaced. • Replace only with the same or equivalent type recommended by the manufacturer. • Dispose of used batteries according to your local regulations. • Do not mix different types of batteries or new and old batteries.
Installation Connecting the Projector +12V Output MOLEX MOLEX 3 3 2 5 7 4 10 6 11 molex molex PB/MOUSE HDMI VGA-OUT VGA1-IN / YPbPr S-VIDEO VIDEO RS-232 AUDIO1-IN (VGA1/VGA2) SERVICE MIC 12V OUT AUDIO 2-IN (S-VIDEO/VIDEO) 1 USB / L R AUDIO OUT PS50426E (*) Optional accessory VGA2-IN / YPbPr DISPLAY R Due to the difference in applications for each country, some regions may have different accessories. RJ-45 9 8 Audio Output 1............................................
Installation Connect to Video Sources DVD Player, Set-top Box, HDTV receiver S-Video Output 6 4 7 Composite Video Output 8 2 12 5 3 +12V Output PB/MOUSE HDMI VGA-OUT VGA1-IN / YPbPr S-VIDEO VIDEO RS-232 AUDIO1-IN (VGA1/VGA2) SERVICE 1 RJ-45 VGA2-IN / YPbPr MIC 12V OUT AUDIO 2-IN (S-VIDEO/VIDEO) DISPLAY USB / L R AUDIO OUT R PS50426E 9 Audio Output Due to the difference in applications for each country, some regions may have different accessories.
Installation Powering the projector On / Off Powering On the Projector When Power mode (Standby) is set to Eco (<1W), the VGA output, Audio pass-through and RJ45 will be deactivated when the projector is in standby. 1. Remove the lens cap. 2. Securely connect the power cord and signal cable. When connected, the POWER/STANDBY LED will turn Amber. 3. Turn on the lamp by pressing “ ” button either on the top of the projector or on the remote. The POWER/STANDBY LED will now turn Green.
Installation Powering off the projector 1. Press the “ ” button on the remote control or on the control panel to turn off the projector. The following message will be displayed on the screen. Press the “ ” button again to confirm otherwise the message will disappear after 15 seconds. When you press the “ ” button for the second time, the projector will display countdown timer and will shut down. 2.
Installation Adjusting the Projected Image Adjusting the Projector’s Height The projector is equipped with elevator feet for adjusting the image height. 1. Locate the adjustable foot you wish to modify on the underside of the projector. 2. Rotate the adjustable ring clockwise to raise the projector or counter clockwise to lower it. Repeat with the remaining feet as needed.
Installation Adjusting the Projector’s Focus To focus the image, rotate the focus ring until the image is clear. XGA series: The projector will focus at distances from 1.64 to 12.46 feet (0.5 to 3.8 meters). WXGA series: The projector will focus at distances from 1.64 to 11.15 feet (0.5 to 3.4 meters). Focus Ring Adjusting Projection Image Size XGA series: Projection Image Size from 41.0” to 312.0” (1.0 to 7.9 meters). WXGA series: Projection Image Size from 44.6” to 303.0” (1.1 to 7.7 meters).
Installation XGA Diagonal length (inch) size of 4:3 Screen Screen Size W x H (m) Projection Distance (D) (inch) (m) Offset (Hd) (feet) Width Height Width Height wide tele wide tele (m) (feet) 40.00 0.81 0.61 31.89 24.02 0.50 0.50 1.64 1.64 0.09 0.30 60.00 1.22 0.91 48.03 35.83 0.80 0.80 2.62 2.62 0.14 0.45 70.00 1.42 1.07 55.91 42.13 0.90 0.90 2.95 2.95 0.16 0.53 80.00 1.63 1.22 64.17 48.03 1.00 1.00 3.28 3.28 0.18 0.60 90.00 1.83 1.37 72.
User Controls Control Panel & Remote Control SO UR CE Control Panel LAMP TEMP MENU POWER/STANDBY Using the Control Panel POWER Refer to the “Power On/Off the Projector” section on pages 14-15. RE-SYNC Automatically synchronize the projector to the input source. Enter / Help / Confirm your item selection. H elp Menu (only available when OSD menu is not shown). SOURCE Press “SOURCE” to select an input signal. Menu Press “Menu” to launch the on-screen display (OSD) menu.
User Controls Remote Control Using the Remote Control Power Refer to the “Power On/Off the Projector” section on pages 14-15. L Button Mouse left click. R Button Mouse right click. Page + Use this button to page up. Page - Use this button to page down. Confirm your item selection. Enter English 20 / Help H elp Menu (only available when OSD menu is not shown). Source Press “Source” to select an input signal. Re-SYNC Automatically synchronizes the projector to the input source.
User Controls Using the Remote Control AV mute Momentarily turns off/on the audio and video. S-Video Press “S-Video” to choose S-Video source. VGA Press “VGA” to choose VGA sources. Video Press “Video” to choose Composite video source. Interactive Pen Using the Interactive Pen ON/OFF Power On/Off the Interactive Pen. LED Indicate the interactive pen’s status. LED Indicate the interactive pen’s battery consumption. Nib Press the nib to draw or write. Mouse Left Click Mouse left click.
User Controls Using the HELP button The HELP function ensures easy setup and operation. Press the “?” button on the remote control or press the “HELP” button on the control panel to open the Help Menu.
User Controls Help menu button functions only when no input source is detected. Please refer to the “Troubleshooting” section on pages 70-75 for more details.
User Controls If input source is detected and help button is pressed, the following pages will appear to help diagnose any problems.
User Controls 25 English
User Controls On-screen Display Menus The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. How to operate 1. To open the OSD menu, press “Menu” on the Remote Control or Projector Keypad. 2 When OSD is displayed, use keys to select any item in the main menu. While making a selection on a particular page, press or “Enter” key to enter sub menu. 3. Use using keys to select the desired item and adjust the settings key. 4.
User Controls Menu Tree Main Menu Image Sub Menu Settings Display Mode Brightness Presentation / Bright / Movie / sRGB / Blackboard / Classroom / User / 3D 0~100 Contrast 0~100 Sharpness 0~31 #1 Color 0~100 #1 Tint #7 0~100 Advanced Gamma Film / Video / Graphics / Standard BrilliantColor™ 0~10 Color Temp.
User Controls Main Menu Sub Menu Setup Projector ID Mute Volume Audio Input Advanced Network Options Source Lock High Altitude Information Hide Keypad Lock Background Color IR Receiver Advanced Lamp Settings PointBlank Settings Logo Logo Capture Closed Captioning Exit Network State DHCP IP Address Subnet mask Gateway DNS Apply Exit Top Receiver Front Receiver Direct Power On Auto Power Off (min.) Sleep Timer (min.
User Controls Please note that the on-screen display (OSD) menus vary according to the signal type selected and the projector model you are using. (#1) “Color” and “Tint” are only supported in Video mode. (#2) For XGA model only. (#3) For WXGA model only. 16:9 or 16:10 depend on “Screen Type” setting. (#4) “3D Sync Invert” is only available when 3D is enabled. (#5) “Signal” is only supported in Analog VGA (RGB) signal. (#6) MIC volume can also be controlled by “Setup Volume” in OSD.
User Controls IMAGE Display Mode There are many factory presets optimized for various types of images. Presentation: Good color and brightness from PC input. Bright: Maximum brightness from PC input. Movie: For home theater. sRGB: Standardised accurate color. Blackboard: This mode should be selected to achieve optimum color settings when projecting onto a blackboard (green). Classroom: This mode is recommended for projecting in a classroom. User: User’s settings.
User Controls Sharpness Adjust the sharpness of the image. Press the Press the Color “Color” and “Tint” functions are only supported under Video mode. to decrease the sharpness. to increase the sharpness. Adjust a video image from black and white to fully saturated color. Press the Press the Tint to decrease the amount of saturation in the image. to increase the amount of saturation in the image. Adjust the color balance of red and green.
User Controls IMAGE | Advanced Gamma This allows you to choose a degamma table that has been fine-tuned to bring out the best image quality for the input. Film: for home theater. Video: for video or TV source. Graphics: for image source. Standard: for PC or computer source. BrilliantColor™ This adjustable item utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing true, more vibrant colors in picture. The range is from “0” to “10”.
User Controls Color Space Select an appropriate color matrix type from AUTO, RGB or YUV. Input Source Use this option to enable / disable input sources. Press to enter the sub menu and select which sources you require. Press “Enter” to finalize the selection. The projector will not search for inputs that are not selected.
User Controls DISPLAY Format Use this function to choose your desired aspect ratio. XGA 4:3: This format is for 4×3 input sources. 16:9-I: This format is for 16×9 input sources, like HDTV and DVD enhanced for Wide screen TV. (576i/p) 16:9-II: This format is for 16×9 input sources, like HDTV and DVD enhanced for Wide screen TV. (480i/p) Native: This format displays the original image without any scaling. AUTO: Automatically selects the appropriate display format.
User Controls WXGA 4:3: This format is for 4×3 input sources. 16:9: This format is for 16×9 input sources, like HDTV and DVD enhanced for Wide screen TV. 16:9 or 16:10 depend on “Screen Type” setting. 16:10: This format is for 16×10 input sources, like widescreen laptops. LBX: This format is for non-16x9, letterbox source and for users who use external 16x9 lens to display 2.35:1 aspect ratio using full resolution. Native: This format displays the original image without any scaling.
User Controls Edge Mask Each I/O has different setting of “Edge mask”. “Edge mask” and “Zoom” can’t work at same time. Edge mask function removes the noise in a video image. Edge mask the image to remove video encoding noise on the edge of video source. Zoom Press the to reduce the size of an image. Press the to magnify an image on the projection screen. H Image Shift Shift the projected image position horizontally. V Image Shift Shift the projected image position vertically.
User Controls DISPLAY | 3D 3D Mode “IR” options may vary according to model. “3D Sync Invert” is only available when 3D is enabled and this mode 3D is for DLP link glass only. Off: Select “Off” to turn 3D settings off for 3D images. DLP Link: Select “DLP Link” to use optimized settings for DLP Link 3D images. IR: Select “IR” to use optimized settings for IR-based 3D images. 3D Sync. Invert Press the “On” to invert left and right frame contents.
User Controls SETUP Language Choose the multilingual OSD menu. Press or into the sub menu and then use the or key to select your preferred language. Press “Enter” to finalize the selection. “Screen Type” is for WXGA only. Screen Type Choose the screen type from16:10 or 16:9. Projection Front-Desktop This is the default selection. The image is projected straight on the screen. Rear-Desktop and Rear-Ceiling are to be used with a translucent screen.
User Controls Rear-Ceiling When selected, the image will appear reversed in upside down position. Menu Location Choose the menu location on the display screen. Projector ID ID definition can be set up by menu (range 0-99), and allow user control an individual projector by RS232. Refer to pages 81-84 for the complete list of RS232 commands. Mute Choose the “On” to turn mute on. Choose the “Off” to turn mute off.
User Controls SETUP Volume Volume adjustment can also control MIC volume. Press the Press the to decrease the volume. to increase the volume. Audio Input The default audio settings are on the back panel of the projector. Use this option to reassign any of the Audio Inputs (1 or 2) to the current image source. Each Audio input can be assigned to more than one video source. Audio 1: VGA 1 and VGA 2. Audio 2: S-Video/Video.
User Controls SETUP | Signal (RGB) “Signal” is only supported in Analog VGA (RGB) signal. Automatic Automatically selects the signal. If you use this function, the Phase, frequency items are grayed out, and if Signal is not automatic, the phase, frequency items will appear for user to manually tune and saved in settings after that for next time projector turns off and on again. Phase Synchronize the signal timing of the display with the graphic card.
User Controls SETUP | Security Security On: Choose “On” to use security verification when the turning on the projector. Off: Choose “Off” to be able to switch on the projector without password verification. Security Timer Password default value is “1234” (first time). Use this function to set the how long (Month/Day/Hour) the projector can be used. Once this time has elapsed you will be requested to enter your password again. Change Password First time: 1. Press “ ” to set the password. 2.
User Controls If the incorrect password is entered 3 times, the projector will automatically shut down. If you have forgotten your password, please contact your local office for support.
User Controls SETUP | Advanced Logo Use this function to set the desired startup screen. If changes are made they will take effect the next time the projector is powered on. Optoma: The default startup screen. Neutral: Logo is not displayed on startup screen. User: Use stored picture from “Logo Capture” function. For successful logo capture, please ensure that the onscreen image does not exceed the projector’s native resolution. (XGA:1024x768 or WXGA:1280x800).
User Controls SETUP | Network Network State Display the network connection status. DHCP Use this function to select your desired startup screen. If you change the setting from one to another, when you exit the OSD menu, the new setting will take effect on next open. On: Assign an IP address to the projector from an external DHCP server automatically. Off: Assign an IP address manually. IP Address Select an IP address. Subnet Mask Select subnet mask number.
User Controls How to use web browser to control your projector 1. Turn on DHCP to allow the DHCP server to automatically assign an IP, or manually enter the required network information. 4. Based on network web-page for the input-string in [tools] tab, the limitation for Input-Length is in the below list (“space” and the other punctuation key included): Category Crestron Control Projector 2. Then choose apply and press “ ” button to complete the configuration process. 3.
User Controls When making a direct connection from your computer to the projector Step 1: Find an IP Address (192.168.0.100) from LAN function of projector. Step 2: Select apply and press “Enter” button to submit function or press “menu” key to exit. Step 3: To open Network Connections, click Start, click Control Panel, click Network and Internet Connections, and then click Network Connections.
User Controls Crestron RoomView Control Tool Crestron RoomView™ provides a central monitoring station for 250+ control systems on a single Ethernet network (more are possible, the number depends on the combination of IP ID and IP address). Crestron RoomView monitors each projector, including projector’s online status, system power, lamp life, network setting and hardware faults, plus any custom attribute as defined by the Administrator.
User Controls 3. Edit Attribute 4. Edit Event For more information, please visit http://www.crestron.com & www.crestron.com/getroomview.
User Controls OPTIONS Source Lock On: The projector will only search current input connection. Off: The projector will search for other signals if the current input signal is lost. High Altitude When “On” is selected, the fans will spin faster. This feature is useful in high altitude areas where the air is thin. Information Hide On: Choose “On” to hide the info message. Off: Choose “Off” to show the “searching” message.
User Controls Reset Choose “Yes” to return the display parameters on all menus to the factory default settings.
User Controls OPTIONS | Advanced Direct Power On Choose “On” to activate Direct Power mode. The projector will automatically power on when AC power is supplied, without pressing the “ ” key on the projector control panel or on the remote control. Auto Power Off (min) Sets the countdown timer interval. The countdown timer will start, when there is no signal being sent to the projector. The projector will automatically power off when the countdown has finished (in minutes).
User Controls OPTIONS | Lamp Settings Lamp Hours Display the projection time. Lamp Reminder Choose this function to show or to hide the warning message when the changing lamp message is displayed. The message will appear 30 hours before suggested replacement of lamp. Brightness Mode When ambient temperature is over 35°C in operating, the projector will switch to Eco automatically. Eco.: Choose “Eco.” to dim the projector lamp which will lower power consumption and extend the lamp life.
User Controls OPTIONS | PointBlank Interactive Choose “On” to enable Interactive and activate the Interactive menu. Dual Pen Interactivity is supported only in the following input modes: VGA and HDMI from a PC, and Wireless Display, USB Display, and LAN Display Interactive Pen is supported in 3D source of 120Hz DLP-Link. The response time lag of Dual Pen operation is 180ms. Choose “On” to enable dual pen simultaneously.
User Controls Choose this function to select the function of the Menu on the interactive pen. button Pointer Motion: Function as toggling among “Normal”, “Draw”, and “Stable” mode PowerPoint Annotation: Function as annotating in the PowerPoint slide show. Switch Windows (Alt+Tab): Function as toggling among windows,acting as the keyboard shortcut Alt+Tab. Esc: Function as the keyboard Esc button. Show Desktop (Cmd+D): Function as showing desktop, minimizing all windows.
User Controls Ruby Introduction Ruby is a embedded project which can bring the high performance in network projection. Base on network protocol, user can configure the projector remotely. It supports to connect the PC with Projector by USB, Ethernet, and Wireless. This project makes full use of the network capability. It allows the administrator to control all the projectors in one building by one PC.
User Controls 2 There are 3 options in this page. •C lick “Download”, it displays the interface to download the software of “Optoma Presenter”. • Click “Crestron”, to enter the control page of Flash UI. • Click “Admin”, the log-in page shows up. 3. Enter the password and click [Login] button, and then main page is displayed. The default password is “admin” when target system is brand new. The maximum password is 8 characters with any characters except “space”. 4.
User Controls Alert Setup This page is to set up the alert notification for kinds of error types by sending mail. Alert type is multi-options. SMTP Mail Setup This page is to set up the details of mail sending, ex. mail server IP address, user name, password and mail address of receivers. (Note: Multi-receivers are separated by semicolon.) Network Setup This page is to set up network parameters of IP, DHCP Server, and wireless.
User Controls • IP Setup: Click “Obtain an IP address automatically” as auto mode; click “Use the following IP Address” as static mode, IP Address/Subnet Mask/Default Gateway/ DNS Server are required to be filled and then click “Apply” button. • DHCP Server Setup: Enable/Disable, Start IP, End IP, Subnet Mask, Default Gateway, DNS server. • Wireless Setup: Connect with wireless dongle, and then setup WLAN mode, SSID, KEY, Channel etc.
User Controls Click the following icons under “Play Control” • : Click to disconnect host PC. • : Click to switch session to background. • : Click to change display region. Crestron RoomView This is the control page of Flash UI. Click “Power” to control power on/off of projector. Click “Vol-, Mute, Vol+” to control volume. In the SourceList, it includes all sources that the projector can process.
User Controls Click “Tools”, the following items are included: • Crestron Control: the basic network information of the control system device. • Projector: the ID of each projector in a building for Administrator to control. • User Password: change user’s password. • Default Language: set the default language. • DHCP: enable/disable DHCP and the details of network card. • Admin Password: change administrator’s password. After change each items, click “Send” button to make it effect.
User Controls Click “Help” to inform administrator to do related protection or operation. Reset to Default Click “Apply” to reset system to the default settings. Click “Flash Upgrade” to upgrade the Firmware from USB disk, which has been inserted in projector. Reboot System Click “Reboot” to reboot system.
User Controls How to use the Card Reader The Card Reader application can display packaged images in a USB flash device. 1. Plugging the USB device into USB port of projector, source of Flash Drive is detected, and then USB Flash Devices Detection Screen is displayed. It supports 3 USB devices at the same time. 2. Press “Enter” to enter Thumbnail mode, different photos in different folders can be chosen; press “Menu” to open menu.
User Controls • File Name On/OFF: Enable/Disable file name display in Thumbnail Display Mode. Press Up/Down/Left/Right key to choose different functions and press Enter key to make it effect. 3. In the menu of Thumbnail mode, choose Display function, or choose file and press “Enter” to enter Display mode. The following buttons are supported in the user interface: • Display: Enter the Image Display Mode. • Thumbnail: Enter the Thumbnail Display Mode. • Slide Show: Enter the Slide Show Mode.
User Controls •S top: Stop Slide Show Mode. •D elay 3/4/5: Slide Show delay in seconds. •S lide Effect: Following modes are supported. (Slide Right/Slide Down/Slide Up/Slide Auto) • Repeat ON/OFF: Enable/Disable Slide Show Repeat Mode. Press Up/Down/Left/Right key to choose different functions and press Enter key to make it effect. When the image can NOT be displayed due to memory limitation or can NOT support image format, the specific image is displayed on the center of the screen.
User Controls How to use the Optoma Presenter Optoma Presenter application allows remote desktop from a host PC to be displayed on the network display through Ethernet, USB, or Wireless transports. It can adapt to different network settings (DHCP, fixed IP, and direct link by USB/Ethernet cable). This software can be downloaded from web page. Before using this function, a USB cable is needed to connect the Projector and PC Host directly. When the connection is OK, the PC will show a USB device disk.
User Controls Click the button to enter Connect and Search Menu. 1. E nter IP address of projector, select the option “Directly”, and then click “Connect” button to enter log-in interface; or Click “Search” button to search the projectors on network and select projectors to connect. 2. I nput “User type” and “Password” in log-in interface. Display port can be selected, default is “Full screen”. 3.
User Controls • Fixed size mode: FIXED mode allows the user to place a frame on the desktop and only the image enclosed inside the frame is transferred to remote network display. The user can change the width and height of the frame by setting up in page “Parameter Setting”->”Basic Setting” or change the size of frame in ALTERABLE mode and move the frame by dragging the frame with mouse. • Alterable size mode: ALTERABLE mode the only region capture is the one enclose by the frame.
User Controls • : For Administrator user login. • : For Normal user login. • : Status of the connection for connected • : Status of the connection for not connected. • : For the status and display position of local screen on the network display, change it by clicking on it and a dialog box appears. • : Click this unlock icon, the password can be changed. (Password change to target network display, only a connection with an Administrator user logged in can change the password.
Appendices Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. No image appears on-screen Ensure all the cables and power connections are correctly and securely connected as described in the “Installation” section. Ensure all the pins of connectors are not bent or broken. Check if the projection lamp has been securely installed.
Appendices 7. Click on “Show all devices”. Next, select “Standard monitor types” under the SP box; choose the resolution mode you need under the “Models” box. 8. Verify that the resolution setting of the monitor display is lower than or equal to UXGA (1600 × 1200). If you are using a Notebook: 1. First, follow the steps above to adjust resolution of the computer. 2. Press the appropriate keys listed below for your notebook manufacturer to send signal out from notebook to projector.
Appendices Image is out of focus Make sure the lens cap is removed. Adjust the Focus Ring on the projector lens. Make sure the projection screen is between the required distance. See page 18. The image is stretched when displaying 16:9 DVD title When you play anamorphic DVD or 16:9 DVD, the projector will show the best image when the projector display mode is set to 16:9 in the OSD. If you play 4:3 format DVD titles, please change the format to 4:3 in the projector OSD.
Appendices The projector stops responding to all controls If possible, turn off the projector, then unplug the power cord and wait at least 60 seconds before reconnecting power. Check that “Keypad Lock” is not activated by trying to control the projector with the remote control. Lamp burns out or makes a popping sound When the lamp reaches its end of life, it will burn out and may make a loud popping sound. If this happens, the projector will not turn on until the lamp module has been replaced.
Appendices On Screen Messages Temperature warning: Fan failed: Lamp warning: Out of display range: If the remote control does not work Check the operating angle of the remote control is within ±15° both horizontally and vertically of one of the IR receivers on the projector. Make sure there are not any obstructions between the remote control and the projector. Move to within 7 m (±0°) of the projector. Make sure the batteries are inserted correctly.
Appendices If the Interactive pen does not work Check the input source is PC (VGA, HDMI, Wireless and LAN source) Check the Interactive function is turned On. When using Wireless or LAN connection, and the Pen does not work, check if the Wireless/Network function is turned On. If more than one Pen point toward the screen at the same time, none can function. Check the Nib, If the Nib is worn out, replace with a new Nib. Make sure the batteries are inserted correctly.
Appendices Replacing the lamp The projector automatically detects the lamp life. When the lamp life is nearing the end of use, you will receive a warning message. When you see this message, please contact your local reseller or service center to change the lamp as soon as possible. Make sure the projector has been cooled down for at least 30 minutes before changing the lamp. Warning: If ceiling mounted, please use caution when opening the lamp access panel.
Appendices 1 The screws on the lamp cover and the lamp cannot be removed. The projector cannot be turned on if the lamp cover has not been placed back on the projector. 2 4 3 Do not touch the glass area of the lamp. Hand oil can cause the lamp to shatter. Use a dry cloth to clean the lamp module if it was accidentally touched. Lamp Replacement Procedure: 1. 2. 3. 4. 5. 6. 7. Switch off the power to the projector by pressing the “ ” button.
Appendices Compatibility Modes Computer Compatibility For widescreen resolution (WXGA), the compatibility support is dependent on Notebook/PC models. 120Hz input signals may be dependent on graphics cards support. Please note that using resolutions other than native 1024 x 768 (XGA model), 1280 x 800 (WXGA model) may result in some loss of image clarity. For WXGA model only.
Appendices Computer Compatibility Mode Resolution V-Sync (Hz) H-Sync (KHz) MAC LC 13” 640 × 480 66.66 34.98 MAC II 13” 640 × 480 66.68 35.00 MAC 16” 832 × 624 74.55 49.73 MAC 19” 1024 × 768 75 60.24 MAC 1152 × 870 75.06 68.68 MAC G4 640 × 480 60 31.35 i MAC DV 1024 × 768 75 60.00 i MAC DV 1152 × 870 75 68.49 Video Compatibility NTSC M (3.58MHz), 4.
Appendices RS232 Commands and Protocol Function List RS232 Pin Assignments 1 2 3 RS232 shell is grounded. English 80 Pin no. Spec.
Appendices RS232 Protocol Function List XX=00-99, projector's ID, Baud Rate : 9600 XX=00 is for all projectors Data Bits: 8 Parity: None RS232 & Telnet Command v1.3 1.Optoma There isEX610STi/EW610STi a after Stop Bits: 1 --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------all Rate ASCII Baud : 9600commands.
Appendices --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------~XX39 11 7E 30 30 33 39 20 31 31 0D Flash Drive ~XX39 12 7E 30 30 33 39 20 31 32 0D Presenter(LAN+Wireless) ~XX39 13 7E 30 30 33 39 20 31 33 0D USB Display ~XX44 n 7E 30 30 34 34 20 a 0D Tint n = 0 (a=30) ~ 100 (a=31 30 30) ~XX45 n 7E 30 30 34 35 20 a 0D Color n = 0 (a=30) ~ 100 (a=
Appendices --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------~XX81 n 7E 30 30 38 31 20 a 0D Volume n = 0 (a=30) ~ 20 (a=32 30) ~XX82 1 7E 30 30 38 32 20 31 0D Logo Optoma ~XX82 2 7E 30 30 38 32 20 32 0D User ~XX82 3 7E 30 30 38 32 20 33 0D Neutral ~XX83 1 7E 30 30 38 33 20 31 0D Logo Capture ~XX88 0 7E 30 30 38 38 20 30 0D Closed Captioning O
Appendices --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------READ from projector (telnet supported) --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------232 ASCII Code HEX Code Fu
Appendices Wall Mount Installation 1. To prevent damage to your projector, please use the Optoma ceiling mount. 2. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector meet the following specifications: 53.38 306.00 110.00 54.64 76.52 82.30 Warning: 1. If you buy a ceiling mount from another company, please be sure to use the correct screw size. Screw size will vary depending on the thickness of the mounting plate. 2.
Appendices Optoma Global Offices For service or support please contact your local office. USA 3178 Laurelview Ct. Fremont, CA 94538, USA www.optomausa.com Canada 2420 Meadowpine Blvd., Suite #105 Mississauga, ON, L5N 6S2, Canada www.optoma.ca 888-289-6786 510-897-8601 services@optoma.com 888-289-6786 510-897-8601 services@optoma.com Europe 42 Caxton Way, The Watford Business Park Watford, Hertfordshire, WD18 8QZ, UK +44 (0) 1923 691 800 www.optoma.
Appendices Benelux BV Randstad 22-123 1316 BW Almere The Netherlands Latin America 3178 Laurelview Ct. Fremont, CA 94538, USA www.optomausa.com +31 (0) 36 820 0253 +31 (0) 36 548 9052 www.optoma.nl 888-289-6786 510-897-8601 services@optoma.com Korea WOOMI TECH.CO.,LTD. 4F,Minu Bldg.33-14, Kangnam-Ku, seoul,135-815, KOREA +82+2+34430004 +82+2+34430005 Japan 東京都足立区綾瀬3-25-18 株式会社オーエス コンタクトセンター:0120-380-495 Taiwan 5F., No. 108, Minchiuan Rd. Shindian City, Taipei Taiwan 231, R.O.C. www.optoma.com.
Appendices Regulation & Safety Notices This appendix lists the general notices of your projector. FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Appendices Operation conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation. Notice: Canadian users This Class B digital apparatus complies with Canadian ICES-003.
